Demonstration Dynamo Model

Demonstration Dynamo Model

Product Code : JL-ETE-7702

Demonstration Dynamo Model
The model may also be used as a motor on 6-8 V DC supply.
It is coupled to the smaller dynamo pulley by a rubber belt to give a step-up ratio.
Electrical output is via a pair of 4 mm sockets and a lamp is provided as a simple output indicator.
This Model uses the same basic assembly as Demonstration Electric Motor except it is mounted on a base plate (230 x 90 mm) which also carries a hand-drive pulley of 120 mm diameter.

    Please Login To Download pdf
