Flow Meter Demonstration

Flow Meter Demonstration

Product Code : JL-HAP-8918

Flow Meter Demonstration
Description:-
The equipment consists of a Venturi meter, variable area meter, an orifice plate, installed in a series configuration to permit direct comparison.
A flow control valve permits variation of the flow rate through the circuit.
Pressure tapping is incorporated so that the head loss characteristics of each flow meter may be measured.
These tappings are connected to an eight tube manometer bank incorporating a manifold with air bleed valve.
Pressurization of the manometers is facilitated by a hand pump.
The circuit and manometer are attached to a support framework which stands on the working top of the Hydraulics Bench.
The bench is used as the source of water supply and for calibrating volumetric each flow meter.

Experimental Capabilities:-
Directly comparing flow measurement using a Venturi meter, variable area meter, an orifice plate.
Calibrating each flow meter using the volumetric measuring tank of the bench.
Pressure tapping to measure heat loss from each meter.
Comparing pressure drops across each device.
Venturi meter, variable area meter and orifice plate with the control valve.
