Particle Size Analysis Test Set

Particle Size Analysis Test Set

Product Code : JL-SM-8868

Particle Size Analysis Test Set
Specification:-
Capacity: 8 hydrometer jars.
Construction: Stainless steel tank; enamel finish exterior.
Jar Support: Stainless steel grid.
Temperature Range: Ambient to 60°C (140°F).
Sensitivity: ±0.2°C at 20°C (68°F).
Circulating System: Drive pump with motor.
Heating System: Immersion type; 700-watt heater in stainless steel mixing chamber.
Plumbing Ports: Overflow; Drain; Inflow and outflow for the cooling system.
Inside Dimensions: 959 x 197 x 419 mm (37-3/4" w. x 7-3/4" d. x 16-1/2" h.).
Outside Dimensions: 1,016 x 254 x 584 mm. (40" w. x 10" d. x 23" h).
Weight: Net 36 kg 80 lbs.
110vAC to 230vAC, 50/60 Hz.
