Bio Waste Oil Fired Medical Incinerator Manufacturer,Supplier and Exporter in India
Product Code : EL-I-2427
Jlab Export is a leading Bio Waste Oil Fired Medical Incinerator Manufacturer,and suppliers in India
Bio Waste Oil Fired Medical Incinerator (code EL-I-2427) is an oil-fired incinerator with primary and secondary chambers for bio-medical waste and other combustible solid waste, built for capacities from 5 to 75 kg per hour. After burning, most combustible solid waste is left at nearly 2–3 percent of its original weight. JLab designs and builds each unit in Ambala, India, to suit the waste it will burn.
Specifications
| Parameter | Detail |
|---|---|
| Burner | Oil fired; secondary burners |
| Chambers | Primary and secondary |
| Capacity | 5 to 75 kg/hr |
| Waste reduction | Most combustible solid waste to nearly 2–3% by weight |
| Components | Air blowers, feeding door, chimney; ash collection pit with ash tray (optional) |
| Lining | High-temperature refractory |
| Construction | Modular, assembled at site |
| Fuel options | Oil, gas or electric |
| Material | Stainless steel |
| Quality check | Each incinerator is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 14–18 working days |
| Product code | EL-I-2427 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Primary and Secondary Chambers
Waste goes in through the feeding door to the primary chamber, where the oil-fired burner burns it. The gases pass to the secondary chamber, where the secondary burners burn them further before the flue gas leaves by the chimney, and air blowers supply the combustion air. The steel body is lined with high-temperature refractory, and the modular construction lets the parts be assembled at site; an ash collection pit with ash tray is optional.
Fuel Options and Users
Besides this oil-fired version, the design is available gas-fired or electrically heated, with burners or electric heating elements. It is offered to hospitals, nursing homes and institutions, and for industrial, camp and municipal waste, shopping centres and animal farms such as sheep kennels.
Other Waste Incinerators
- Electronic Bio Waste Medical Incinerator — bio-medical model fitted with a scrubber.
- Industrial Waste Incinerator — a separate incinerator design for industrial waste.
- Electrical Incinerator — electrically heated two-chamber unit for office waste.
JLab lists every model under Incinerator, part of Metallurgical Equipment.
Request a Quote
Give the capacity in kg per hour, the fuel, the waste to be burnt and the site address through Add To Cart or the contact page.
