LED Top and Bottom Lights Binocular Stereo Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-8092
Jlab Export is a leading LED Top and Bottom Lights Binocular Stereo Microscope Manufacturer,and suppliers in India
LED Top and Bottom Lights Binocular Stereo Microscope (code EL-M-8092) is a compact binocular stereo microscope with an incident LED top light and a transmitted LED bottom light, one achromatic objective chosen from 1X, 2X, 3X or 4X, and paired WF 10X eyepieces for 10X to 40X. Three rechargeable batteries and a charging adapter are included. JLab assembles this LED model at Ambala in India.
Specifications
| Parameter | Detail |
|---|---|
| Objective | 1X, 2X, 3X or 4X achromatic; parfocal and parcentred |
| Magnification | 10X, 20X, 30X or 40X |
| Viewing head | Binocular, 45° inclined; post-mounted, rotates 180° |
| Interpupillary distance | 51–75 mm; diopter adjustment on left tube |
| Eyepieces | Paired WF 10X, two rubber eye guards, setscrew lock; upgradable to 15X or 20X |
| Focusing | Rack and pinion, two knobs, safety stop and tension adjustment |
| Stage plates | 95 mm glass plate and 95 mm reversible black/white plate; locked-on clips |
| Top light | Diagonally adjustable incident LED |
| Bottom light | Transmitted LED |
| Power and switches | Main on/off switch with top/bottom choice; 3 rechargeable batteries and charging adapter |
| Quality check | Each microscope is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 5 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-M-8092 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Top Light or Bottom Light
A main on/off switch powers the lighting and a selector chooses one of two modes. The incident top LED tilts diagonally to light opaque objects from above, placed on the black or white side of the reversible plate. The transmitted bottom LED shines up through the 95 mm glass plate, so thin or translucent specimens are seen against the light. Because the microscope runs on its rechargeable batteries, no socket is needed during use, and the adapter recharges them afterwards.
Setting Up for Each Student
Magnification is fixed by the objective ordered, from 10X with the 1X objective up to 40X with the 4X. The head turns through 180° on its post and is adjusted for working distance, eyepiece spacing runs from 51 to 75 mm, and the left tube has a diopter adjustment. Rubber eye guards shade the eyes, while setscrew-locked eyepieces and locked-on clips stay in place during middle and secondary level lessons.
Related Stereo Models
- Series Binocular Stereo Microscope — same head and objective choice, without built-in lights
- Dual Power LED Stereo Microscope with Pillar Stand — two objectives on a turret and a 3-wire cord
- Cordless Rechargeable Dual Power LED Stereo Microscope — cordless dual power model with a frosted glass stage plate
For more LED and battery models, browse Microscope in Microscope Lab Equipment.
Request a Quote
Choose the objective (1X, 2X, 3X or 4X) and quantity, then use Add To Cart or our contact page, adding the delivery address.
