Basic PLC Trainer Manufacturer,Supplier and Exporter in India
Product Code : EL-FOT-10256
Jlab Export is a leading Basic PLC Trainer Manufacturer,and suppliers in India
Basic PLC Trainer (code EL-FOT-10256) is a PLC trainer that puts real sensors and actuators on the same board as its 32-bit CPU controller, so that first programs can react to objects and drive motors. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Controller | 32-bit CPU controller; 8 digital inputs; 6 digital outputs |
| Memory | Program capacity 8K steps; data registers 5K words |
| Pulse outputs | 4 points, 10 kHz |
| High-speed counters | 8 points: 4 at 20 kHz, 4 at 10 kHz |
| Communication | Modbus RTU protocol; RS-232 link for PC communication |
| Digital input simulation | 6 toggle switches and 2 push switches for High and Low inputs |
| Input levels and supply | High 24 V DC, Low 0 V; built-in +24 V DC supply |
| Digital output simulation | 8 LED indicators |
| On-board sensors | Capacitive pickup, inductive pickup, photo pickup |
| Other on-board devices | Limit switch, emergency switch, DC motor, stepper motor, buzzer, relay, red and green LED lamps |
| Quality check | Each trainer is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-FOT-10256 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How Does It Compare with Other JLab PLC Trainers?
| Model | PLC I/O | Simulation panels and on-board parts |
|---|---|---|
| This trainer (EL-FOT-10256) | 8 digital in, 6 digital out | 6 toggle and 2 push switches; 8 LED indicators; pickups, switches, motors, buzzer, relay and lamps on the board |
| PLC Trainer | 8 digital in, 6 digital out | 6 toggle and 2 push switches; 8 SPDT relay outputs with LED indicators |
| Advanced PLC Trainer | 24 digital in, 22 digital out; 4 analogue in, 2 analogue out | 14 toggle and 2 push switches; 4 potentiometers; 8 SPDT relay outputs with LEDs; optional interfacing simulation modules |
This trainer and the PLC Trainer both use an 8-input, 6-output 32-bit CPU controller; here the outputs are shown on LED indicators and the board carries the sensors and devices for programs to work with. The Advanced PLC Trainer has the larger I/O count and analogue channels.
What Is the Basic PLC Trainer Used For?
It teaches PLC programming with the kind of devices found on a machine. The pickups detect objects, so students can write programs that count items or stop a motor on a real detection; the limit switch and emergency switch bring in end-of-travel and safety logic; and the DC motor, stepper motor, buzzer and lamps give the program something visible and audible to control. The toggle and push switches stand in for any further inputs.
What to Specify When Ordering
- The number of trainers, for example one per pair of students.
- Whether the PLC Trainer or Advanced PLC Trainer should be quoted for the same lab.
- The delivery destination and preferred delivery terms.
Frequently Asked Questions
How does the trainer connect to a PC?
Over an RS-232 link, and the controller supports the Modbus RTU protocol for communication with other devices.
Does the controller handle fast pulse signals?
Yes. It has 8 high-speed counter points, 4 at 20 kHz and 4 at 10 kHz, and 4 pulse outputs at 10 kHz.
What can the three pickups detect?
An inductive pickup senses metal objects, a capacitive pickup also responds to many non-metallic materials, and a photo pickup reacts when an object breaks or reflects its light beam.
What should an export enquiry state?
Quantity, destination country and port or city, delivery terms such as FOB or CIF, packing or labelling needs and any tender reference.
Who manufactures the Basic PLC Trainer?
JLab — Jain Laboratory Instruments Pvt Ltd — at its works in Ambala, Haryana, India.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, a manufacturer of PLC, electronics and other technical trainers in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. Each Basic PLC Trainer leaves JLab’s own works rather than a trader’s store, so polytechnics, colleges, dealers and importers buy it from the maker and go back to the same source for repeat orders and spares. JLab is registered under GSTIN 06AADCJ9848D1ZE and holds Legal Entity Identifier 549300DTGS77DGYD6N03. It exports worldwide and ships to buyers in every region — Tajikistan in Central Asia, Afghanistan in South Asia, Canada in North America, Switzerland in Western Europe and Malawi in East Africa are examples. Tender information is on the JLab lab tenders page.
Related PLC Equipment
- PLC Trainer with Sensors — a PLC experiment box with relays, locking and non-locking buttons, indicator lamps and a potentiometer.
Browse the Fiber Optic Trainers section of Electronics Lab Equipments, where this trainer is listed.
Request a Quote
Send your enquiry with the Add To Cart button or the contact page, with the number of trainers, any other PLC trainers to include and the delivery location.
