Diffraction Grating Manufacturer,Supplier and Exporter in India
Product Code : EL-PL-12530
Jlab Export is a leading Diffraction Grating Manufacturer,and suppliers in India
Diffraction Grating (code EL-PL-12530) carries three 20 x 10 mm gratings with 100, 300 and 600 lines per mm, mounted between glass plates, so one item lets students compare how line spacing changes a spectrum. Each section has a 15 x 10 mm viewing area. JLab builds the grating in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Model | JLG767/018 |
| Gratings | Three, 20 x 10 mm each |
| Line densities | 100, 300 and 600 lines per mm |
| Mounting | Between glass plates |
| Viewing area | 15 x 10 mm per section |
| Quality check | Each grating is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 4–6 working days |
| Product code | EL-PL-12530 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Reading a Spectrum with the Grating Equation
Light of wavelength λ passing a grating of line spacing d forms bright orders at angles θ given by d sin θ = nλ, where n is the order number. The spacing is the reciprocal of the line density: 10 µm for 100 lines per mm, about 3.3 µm for 300 and about 1.7 µm for 600. The finer the grating, the wider each order is spread from the centre and the fewer orders appear, so the 600 lines per mm section gives the broadest first-order spectrum while the 100 lines per mm section shows many orders close together. With θ measured on a spectrometer for a known order, λ = d sin θ / n.
Handling the Glass Mount
Hold the grating by its edges so fingerprints stay off the viewing areas, and set the lines parallel to the slit of the light source or spectrometer.
Related Wave Optics
- Polarizing Filters — linear polarizing film filters in slide frames, for polarization work.
- Diffraction and Interference Study Kit - Teacher’s Demonstration Model — red laser demonstration kit with Young’s slits and diffraction tokens.
- Optics Set OW1, Wave Optics — case of wave optics materials for a series of experiments.
Prisms, slabs and lenses for the rest of the optics course are in Physics Lab.
Request a Quote
Put the grating in an enquiry with Add To Cart or write through the contact page with the quantity and delivery address.
