Product Code : EL-CL-13456
Jlab Export is a leading Set of Coils with Removable Iron Core Manufacturer,and suppliers in India
Set of Coils with Removable Iron Core (code EL-CL-13456) is a group of copper-wound coils of 300, 600 and 1200 turns on hollow formers, with an iron core that slides in or out, for experiments on electromagnetic induction, magnetic fields and current. Square end plates hold each winding and keep the coil steady on the bench, and insulated screw-type binding posts take the leads. The coils and core are made by JLab in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Model | JL/IPL-677 |
| Number of turns | 300, 600, 1200 |
| Windings | Copper |
| Former | Hollow air-core tube |
| Core | Removable iron core |
| Terminals | Insulated screw-type binding posts |
| End plates | Square, hold the windings and support the coil |
| Quality check | Each coil set is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 4–6 working days |
| Product code | EL-CL-13456 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Air Core or Iron Core
With the core taken out, only air fills the tube, and its relative magnetic permeability is close to 1. Nothing inside can saturate, so the field stays proportional to the current. Sliding the iron core in magnetises the iron along the axis and makes the field from the same current much stronger, which is the principle of an electromagnet.
Inducing a Current
A voltage is induced in a coil only while the magnetic flux through it is changing: push a magnet in or pull it out, or switch the current on or off in a second coil placed alongside. A magnet held still or a steady current induces nothing. For the same change of flux, the 1200-turn coil gives a larger induced voltage than the 300-turn one, because every turn adds its share.
Related Electromagnetism Apparatus
- Moving Coil Galvanometer — centre-zero meter that shows which way an induced current flows.
- Power Supply Unit / Block for DC — regulated DC supply for passing current through a coil.
- Permanent Magnet Bar and Horseshoe — bar magnet to move in and out of a coil.
More electricity and magnetism apparatus is in the Chemistry Lab category.
Request a Quote
Add the coil set with Add To Cart, or send the number of sets and the delivery location through the contact page.
