CBSE Physics Lab Equipment Package for School Manufacturer,Supplier and Exporter in India
Product Code : EL-SK-13309
Jlab Export is a leading CBSE Physics Lab Equipment Package for School Manufacturer,and suppliers in India
A physics lab package is a ready-made set of the apparatus a school needs for its practicals, bought as one order instead of item by item. This CBSE package holds 58 lines of instruments, apparatus and teaching aids. It is put together so a class of up to 30 students can work at once.
Specifications
| Curriculum | CBSE school physics |
| Class size | Up to 30 students working at once |
| Line items | 58 |
| Battery eliminators | Four, 2–12 V DC, 2 A |
| Mains input (battery eliminators) | 230 V AC, 50 Hz (110 V on request) |
| Meters | Four ammeters (0–1 A DC), four voltmeters (10 V DC range), one digital multimeter |
| Lenses and mirrors | Concave and convex, 25 cm focal length, five of each |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 14–18 working days |
| Manufacturer | JLab (Jain Laboratory Instruments Pvt Ltd), Ambala, India |
What the Package Contains
For electricity, the set has battery eliminators, ammeters and voltmeters on desk stands, a digital multimeter and two resistance boxes. It adds 1, 10 and 20 ohm resistance coils, three 50 ohm rheostats, plug keys, constantan and copper wire and a dry cell. For magnetism there are bar and U magnets, six compasses and iron filings, with dynamo and electric motor models and a gold leaf electroscope.
The optics items are the lenses and mirrors, five prisms, five glass slabs and a wooden optical bench with lens holders and white screens. Mirror strips, a light box, a periscope, a kaleidoscope, a magnifier and two charts on images formed by mirrors and lenses complete them.
For mechanics, it has an Archimedes set-up with an overflow vessel, 250 ml measuring cylinders, spring balances, aluminium blocks and metre scales. Sound work uses slinky springs, eight tuning forks and a reflection of sound apparatus. Stop watches, burette stands, drawing boards, a geometry box, a wire cutter, pins and thread cover the rest.
Practicals the Package Supports
For the V-I graph of a resistor, students wire a battery eliminator, plug key, rheostat, ammeter and resistance coil in series, with the voltmeter across the coil. The ends of the copper leads are first scraped bright with Sand Paper, and extra Connecting Wires let several groups wire up at once.
The mirror and lens on the optical bench give focal lengths. The glass slab and prism, pinned to a drawing board, show the path of light. Field lines are traced round the bar magnet with the compasses and iron filings.
Frequently Asked Questions
How should the package be checked when it arrives?
Unpack it against the 58-line packing list and count every line. Look over the lenses, mirrors, prisms and slabs for chips and cracks. Switch on each battery eliminator and check its output with the multimeter before the first practical.
Which consumables should be stocked alongside it?
The set includes board pins, paper pins, two rolls of thread, constantan and copper wire and one dry cell. These run out first, so most labs keep extra pins, thread, wire and cells in a separate, labelled store from the start.
What mains supply do the battery eliminators need?
They run on 230 V AC, 50 Hz mains, and 110 V versions are made on request, so state your mains voltage when ordering. Have the lab sockets and wiring checked before use, and keep plugs and leads away from wet hands and sinks.
Which class 10 practicals can be done with this set?
It covers the V-I graph of a resistor and resistors in series and in parallel. It also covers the focal length of a concave mirror and a convex lens, and the path of light through a glass slab and a prism.
How do students find the focal length of the concave mirror quickly?
Point the mirror at a distant object, such as a tree outside the window, and move a white screen until a sharp, upside-down image forms on it. The mirror-to-screen distance is roughly the focal length, close to the 25 cm of the mirrors in this set.
