Complete Mechanics Kit Manufacturer,Supplier and Exporter in India
Product Code : EL-PL-13518
Jlab Export is a leading Complete Mechanics Kit Manufacturer,and suppliers in India
Complete Mechanics Kit (code EL-PL-13518) is a magnetic-board set for moments, pulleys, the inclined plane and spring stiffness. Its disc of moments, lever with 22 equidistant holes, dial force gauges, load cells, hook weights and springs fix to a 600 × 900 mm white erasable magnetic panel, offered as its accessory, so the class sees each arrangement upright. JLab manufactures the kit and its magnetic parts in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Moments | Disc of moments on magnet with set of lugs; metal lever with 22 equidistant holes; axis on magnet |
| Magnetic accessories | 4 pulleys, 2 hooks, 1 ruler |
| Force gauges | 2 magnetic dial force gauges, 2 N |
| Load cells | 4 magnetic load cells, 2 N – 5 N |
| Hook weights | Set of 12 (50, 100 and 200 g) |
| Springs | 3 of different stiffness, with magnetic calibration scale |
| Other parts | Inclined plane and roller; spool of wire; 3 arrows; 2 magnetic triangles; 2 erasable felt-tips |
| Literature | Manual with experiment booklet |
| Storage | Case with captive lid and fold-down handle |
| Accessory | White erasable magnetic panel, 600 × 900 mm, with removable magnetic support feet |
| Quality check | Each kit is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 4–6 working days |
| Product code | EL-PL-13518 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
What the Parts Demonstrate
On the disc of moments or the 22-hole lever, hook weights hung either side of the axis balance when the clockwise and anticlockwise moments are equal, force × distance on each side, with distances counted in hole spacings. The four magnetic pulleys and two hooks build fixed and movable pulley systems, and the two 2 N dial force gauges read the effort; a 200 g hook weight pulls with just under 2 N, so it nearly fills a gauge. The inclined plane and roller show the force needed along a slope, and the three springs, read against the magnetic calibration scale, show that a stiffer spring stretches less under the same load.
Marking Forces on the Panel
The three arrows, two magnetic triangles and two erasable felt-tips let the teacher draw force directions and angles straight onto the panel beside the apparatus, then wipe them off for the next arrangement. The manual and experiment booklet set out the experiments, and the parts go back into the case with its captive lid and fold-down handle after the lesson.
Related Mechanics Sets
- ME2 Mechanical Box, Forces — boxed set for friction, pulleys, hoists and inclined-plane forces.
- ME3+ Mechanical Box — kinematics and energy set with light barriers and a digital counter.
- Inclined Plane — hinged metal plane with angle scale, pulley, roller and mass pan.
More mechanics apparatus is in Physics Lab.
Request a Quote
Start with Add To Cart, or use the contact page to send the number of kits, whether the magnetic panel is wanted, and the delivery address.
