Compound Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-BL-11241
Jlab Export is a leading Compound Microscope Manufacturer,and suppliers in India
Compound Microscope (code EL-BL-11241) is a student microscope with 5x, 10x and 45x objectives on a triple revolving nosepiece and 10x and 15x eyepieces, used for viewing slides in school and college biology labs. Light comes from a plano-concave mirror in a fork mount through a built-in condenser and disc diaphragm. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Type | Student compound microscope |
| Objectives | 5x, 10x and 45x |
| Eyepieces | 10x and 15x |
| Total magnification | 50x to 675x (objective x eyepiece, calculated from the listed optics) |
| Nosepiece | Triple revolving, with click-stop arrangement for centring and repeatable settings |
| Focusing | Separate coarse and fine focusing by rack and pinion |
| Illumination | Plano-concave mirror in fork mount |
| Condenser and diaphragm | Built-in condenser; disc diaphragm |
| Stage | Two spring clips; provision for fitting a mechanical stage |
| Base and body | U-shaped, well-balanced base; heavy inclinable body |
| Finish | Stipple-grey, chemical-resistant baked-on finish |
| Catalogue model number | JL111/1.4 |
| Quality check | Each microscope is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-BL-11241 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How Does It Compare with Other JLab Microscopes?
| Model | Magnification | Condenser and stage | Other listed details |
|---|---|---|---|
| This microscope (EL-BL-11241) | Objectives 5x, 10x, 45x; eyepieces 10x, 15x (50x–675x) | Built-in condenser with disc diaphragm; two spring clips; provision for a mechanical stage | Plano-concave mirror; U-shaped base; inclinable body |
| Compound Microscope | 150x to 675x (as listed) | Abbe-type N.A. 1.25 condenser with iris diaphragm, focusable by rack and pinion; fixed square stage 110 x 110 mm | Monocular body; dust-proof triple nosepiece with click stops; mechanical tube length 160 mm; plano-concave mirror |
| Dissection Microscope | Eyepieces 10x and 20x | Round base with stage clips; detachable hand rests | Joint revolving arm to scan the whole stage; rack-and-pinion focusing; plano-concave mirror |
Choose this model when students need a low 50x starting view for locating specimens and high power for cell detail, with simple spring-clip handling. The other compound microscope suits buyers who want an iris diaphragm and a larger fixed stage, while the dissection microscope is meant for magnified dissection work rather than thin slide preparations.
What Is the Compound Microscope Used For?
A compound microscope magnifies in two stages: the objective forms an enlarged image and the eyepiece enlarges it again, so the total magnification is the product of the two. With the 5x and 10x objectives students locate and scan a specimen at 50x to 150x; the 45x objective gives 450x or 675x for cell detail. In CBSE and ICSE practicals it is used for stained onion peel and cheek cell mounts in class 9, and for a leaf peel showing stomata and prepared slides of binary fission in Amoeba and budding in yeast in class 10. College botany, zoology and microbiology teaching labs use it for routine slide work.
Angle the mirror towards a window or a separate lamp until the field is evenly lit, since no built-in lamp is listed. Clip the slide under the spring clips, focus with the coarse knob on the lowest-power objective while watching from the side so the lens never touches the slide, then sharpen the image with the fine knob. Click the nosepiece round to a higher objective and refocus with fine focus only. After use, return to the low-power objective, cover the microscope against dust, and clean lenses with lens tissue only.
What to Specify When Ordering
- Quantity — the minimum order is 10 microscopes; state the number needed for your lab.
- Mechanical stage — say if you want one for the stage provision, and confirm the fit with JLab.
- Slides — add glass slides, cover slips and prepared slides to the same enquiry.
- Delivery — give the destination and any tender reference for export or institutional orders.
Frequently Asked Questions
What magnifications does this microscope give?
Six combinations: 50x, 75x, 100x, 150x, 450x and 675x. They come from the 5x, 10x and 45x objectives used with the 10x or 15x eyepiece.
Does it need electricity?
No electrical lamp is listed. Light comes from the plano-concave mirror in its fork mount, which reflects daylight or a separate lamp up through the built-in condenser.
Can a mechanical stage be fitted?
Yes, the stage has provision for fitting one. JLab lists a microscope mechanical stage separately; confirm with JLab that it fits this model before ordering both together.
How does it differ from the other JLab compound microscope?
The other model is listed at 150x to 675x with an Abbe-type condenser, an iris diaphragm and a fixed square stage. This one starts lower at 50x thanks to its 5x objective, and uses a disc diaphragm and spring clips.
Are slides included?
No, this listing covers the microscope. Glass slides, cover slips and prepared slides are separate items, linked below, and can be added to the same enquiry.
What information is needed for an export quotation?
Send the quantity, the destination country and port or city, your preferred delivery terms (for example FOB or CIF), any packing or labelling needs, and the tender reference if the order is for a tender.
Who manufactures this microscope?
Jain Laboratory Instruments Pvt Ltd, trading as JLab, makes it at its works in Ambala, Haryana, and quotes for it directly as the manufacturer.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, a biology lab equipment and microscope manufacturer in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. This microscope is assembled at JLab’s own works rather than bought from a trader, so schools, colleges, dealers and importers buy it factory-direct, every unit is inspected by eye before dispatch, and repeat orders and replacement parts are handled by the manufacturer. JLab exports worldwide and ships to buyers in every region — for example the Maldives in South Asia, New Zealand in Oceania, Tajikistan in Central Asia, Eswatini in Southern Africa and Serbia in Southern Europe. Details for institutional purchasing are on the JLab lab tenders page.
Microscopy Accessories and Slides
- Microscope Mechanical Stage — an attachment that holds the slide and moves it with control knobs.
- Glass Slides — clear rectangular glass slides for temporary mounts.
- Cover Slip — square borosilicate glass cover slips.
- Permanent or prepared slides of Binary fission in Amoeba & Budding in Yeast — prepared slides for the class 10 reproduction practical.
- Microscope Eyepiece — replacement oculars offered in 5X and 10X.
See more in the Biology Lab range or the full Biology Lab Equipment catalogue.
Request a Quote
Quotes come direct from the manufacturer. Use the Add To Cart enquiry button on this page, or send the number of microscopes (minimum 10 units), any mechanical stages or slides you want with them, and your delivery location through the contact page.
Last updated: 5 October 2026
