HI-Load 5000 (5kN Loading Device) Manufacturer,Supplier and Exporter in India
.jpg)
Product Code : EL-MI-4923
Jlab Export is a leading HI-Load 5000 (5kN Loading Device) Manufacturer,and suppliers in India
HI-Load 5000 (5kN Loading Device) (code EL-MI-4923) is a 5 kN loading device in which a fine-thread screw jack with 75 mm of travel applies load through a lightweight proving ring, while a digital dial gauge reads the load directly in decanewtons. It is used in structures and strength-of-materials labs and for student projects, in compression or, with the loading yoke provided, in tension. JLab (Jain Laboratory Instruments Pvt Ltd, Ambala, India) supplies it to schools, colleges and dealers.
Specifications
| Parameter | Detail |
|---|---|
| Capacity | 5 kN |
| Loading mechanism | Screw jack with a fine thread |
| Travel | 75 mm |
| Load-measuring element | Lightweight proving ring |
| Loading modes | Compression; tension using the loading yoke provided |
| Read-out | Digital dial gauge showing the load directly in decanewtons; the listing states that the read-out compensates for variations of the ring |
| Zero setting | Zero-setting switch on the gauge removes the effect of self weight and initial set-up |
| Listed uses | HI-PLAN experiments in place of cast iron weights; student projects needing large loads in any direction |
| Quality check | Each device is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-MI-4923 |
| Supplied by | Jain Laboratory Instruments Pvt Ltd (JLab), Ambala, India |
What Is the 5 kN Loading Device Used For?
Most structures and strength-of-materials experiments start by applying a known load — bending a beam, loading a truss or portal frame, compressing a strut or stretching a specimen. Hanging cast iron weights is slow, only pulls downwards and becomes awkward at high loads. A screw-jack loading device replaces the weights: turning the jack deflects the proving ring, and because a ring’s deflection is proportional to the load within its elastic range, the gauge on the ring can show force directly. A decanewton is ten newtons, so the read-out stays in round numbers across the 5 kN capacity.
Because the ring works in compression and the yoke allows tension, and the screw jack gives 75 mm of travel, the device can push or pull in any direction, which suits student project rigs as well as standard frame experiments. Assemble the set-up first, then use the zero-setting switch so that the self weight of the parts is not counted, and apply load in steps while recording deflections or strains.
What to Specify When Ordering
- Your test frame — the frame or rig the device will be mounted on, so fixings can be confirmed.
- Loading direction — compression, tension or both (the loading yoke is provided for tension).
- Read-out instruments — any extra dial gauges or strain meters for the experiment.
- Quantity — the minimum order is 10 units.
Frequently Asked Questions
What load can the HI-Load 5000 apply?
Up to 5 kN. The proving ring is designed for compression, and a loading yoke is provided so that tension loads can also be applied.
How is the load read?
The ring’s deflection drives a digital dial gauge that shows the load directly in decanewtons. A zero-setting switch removes the effect of self weight and the initial set-up of the experiment.
How much travel does the screw jack give?
75 mm, through a fine-thread screw jack, which allows the load to be raised in small, controlled steps.
Can it replace weights in structures experiments?
Yes. The listing describes it as usable for HI-PLAN experiments to avoid cast iron weights, and adaptable for student projects that need large loads in any direction.
Who supplies the HI-Load 5000?
JLab (Jain Laboratory Instruments Pvt Ltd) in Ambala, Haryana, India, supplies it and quotes for it directly, together with its own range of lab equipment.
Supplier
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, a laboratory equipment company in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. It supplies this loading device alongside its own range of engineering and science lab equipment, so institutes, dealers and importers can place one order for a complete lab, and each device is visually inspected before dispatch. JLab exports worldwide and ships to buyers in every region — for example Thailand in Southeast Asia, Eswatini in Southern Africa, Guatemala in Central America and the Caribbean, Nepal in South Asia and Sierra Leone in West Africa. Tender details are on the JLab lab tenders page.
Load and Deflection Measurement
- Proving Rings — steel proving rings supplied with a dial gauge and loading pads, for load measurement and calibration.
- Digital Dial Gauges — electronic indicators for reading beam and frame deflections.
- Analogue Dial Gauges — mechanical dial indicators reading 0.01 mm per division.
- 2 Channel Digital Strain Meter — reads strain gauges on the loaded members.
Browse the Mechanical Engineering Lab Equipment range, or the Measuring Instruments section of the Indian Instruments range.
Request a Quote
Quotes come directly from JLab. Use the Add To Cart enquiry button on this page, or send the quantity (minimum 10 units), the frame it will be used with, any extra gauges and your delivery location through the contact page.
