IC Chip Manufacturer,Supplier and Exporter in India
Product Code : EL-PL-12461
Jlab Export is a leading IC Chip Manufacturer,and suppliers in India
IC Chip (code EL-PL-12461), model JL449/121, is a leaded integrated circuit in a DIP (dual in-line) package, offered in different configurations and type numbers. The 555 timer, used for time delays, pulse generation and oscillators, is a typical example, and the chips work at 5 V. JLab manufactures these chips for electronics practicals in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Model | JL449/121 |
| Type | Integrated circuit, leaded |
| Mounting type | DIP (dual in-line package) |
| Example | 555 timer IC |
| Voltage | 5 V |
| Available in | Different configurations and type numbers |
| Quality check | Each IC chip is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 4–6 working days |
| Product code | EL-PL-12461 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
What the 555 Timer Does
In monostable mode a trigger starts one output pulse whose length is set by an external resistor and capacitor; larger values give a longer pulse, which makes a simple time delay. In astable mode the output keeps switching between high and low by itself, so the chip acts as an oscillator, for example to flash an LED. Used as a flip-flop (bistable), it holds its output high or low until it is told to change. Derivatives put up to four timers in one package.
Handling DIP Chips
Pin 1 sits next to the notch or dot on the top face, and the pins are numbered anticlockwise from there when the chip is viewed from above. Insert it the right way round into a breadboard or IC socket, with the pins straight, and check the supply connections before switching on, as a reversed supply can destroy the chip.
Related Timer Circuit Items
- Capacitor — capacitor for the timer’s resistor–capacitor timing pair.
- Carbon Resistance of Different Values — carbon resistors for setting the timing and LED current.
- LED — 5 mm LED on a board to show the output flashing.
- Logic Gate Apparatus — gate modules with printed truth tables for digital work.
Power supplies and meters for these circuits are in Physics Lab.
Request a Quote
Give the IC type numbers and quantities through Add To Cart or the contact page, along with the delivery address.
