Liebig Condenser Manufacturer,Supplier and Exporter in India
Product Code : EL-SLE-5552
Jlab Export is a leading Liebig Condenser Manufacturer,and suppliers in India
Liebig Condenser (code EL-SLE-5552) is a borosilicate glass Liebig condenser with a 300 mm cooling jacket and a 500 mm condenser tube, listed with an inner tube, plastic nuts and rubber washers. It is used to cool and condense vapour during distillation and reflux in school, college and university chemistry labs. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Type | Liebig condenser |
| Material | Borosilicate glass |
| Jacket length | 300 mm |
| Condenser tube length | 500 mm |
| Fittings | Inner tube with plastic nuts and rubber washers |
| Quality check | Each condenser is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-SLE-5552 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How Does It Compare with Other JLab Liebig Condensers?
| Model | Glass | Listed lengths | Construction details |
|---|---|---|---|
| This condenser (EL-SLE-5552) | Borosilicate | 300 mm jacket; 500 mm condenser tube | Inner tube with plastic nuts and rubber washers |
| Liebig Condenser | Borosilicate, hand blown | 300 mm jacket | 24/40 joints |
| Condensers (Liebig type) | Borosilicate | 500 mm overall | Narrow fused-on jacket |
Choose this model when you want the 300 mm jacket on a 500 mm tube with nut-and-washer fittings. The version with 24/40 joints suits ground-glass distillation sets, and the fused-jacket condenser is an all-glass alternative.
What Is a Liebig Condenser Used For?
A Liebig condenser is a straight inner tube surrounded by a water jacket. Hot vapour from a boiling flask passes along the inner tube, cold water flowing through the jacket takes away its heat, and the vapour condenses into liquid that runs into a receiver. It is the standard condenser for simple distillation, such as separating acetone from water in class 9 science or purifying water and organic liquids in class 12 and college practicals, and it can be clamped upright over a flask for heating under reflux.
Clamp the condenser at its middle, connect the cooling water to the lower inlet and take it out from the upper outlet so the jacket stays full, and turn the water on before you start heating. Check that the nuts are snug and the washers seated before each run, and let the glass cool before dismantling.
What to Specify When Ordering
- Fittings — confirm the end joints and hose connections that match your flasks and receivers.
- Quantity — the minimum order is 10 units; ask about spare washers if you will dismantle the condensers often.
- Distillation set — add distilling flasks, condenser clamps and rubber tubing to the same enquiry.
Frequently Asked Questions
What are the dimensions of this Liebig condenser?
It has a 300 mm cooling jacket on a 500 mm condenser tube, made of borosilicate glass.
What are the plastic nuts and rubber washers for?
The listing describes the inner tube as fitted with plastic nuts and rubber washers. Ask JLab how the condenser is assembled and whether spare washers or inner tubes are available.
Which way should the cooling water flow?
In at the lower connection of the jacket and out at the upper one, opposite to the flow of vapour, so the jacket stays full of cold water.
What joints does it have?
The listing does not state the joint type. JLab also lists a Liebig condenser with 24/40 joints, so tell JLab which joint size your glassware uses.
Can it be used for reflux?
Yes, a Liebig condenser can be clamped vertically above a flask so that vapour condenses and runs back into the flask.
What is needed for an export quotation?
The quantity, any joint or fitting requirements, the destination country and port or city, delivery terms such as FOB or CIF, packing or labelling needs, and the tender reference if any.
Who manufactures this condenser?
JLab, the trading name of Jain Laboratory Instruments Pvt Ltd, makes it at its works in Ambala, Haryana, and quotes for it as the manufacturer.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, a borosilicate glassware and chemistry lab equipment manufacturer in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. This condenser is made at JLab’s own works rather than bought from a trader, so schools, colleges, dealers and importers order it direct from the maker, each condenser is visually inspected before dispatch, and repeat orders are handled by the manufacturer. Its GSTIN is 06AADCJ9848D1ZE and its Legal Entity Identifier is 549300DTGS77DGYD6N03. JLab exports worldwide and ships to buyers in every region — for example Canada in North America, Cameroon in Central Africa, Cambodia in Southeast Asia, Chile in South America and Samoa in Oceania. Tender details are on the JLab lab tenders page.
Distillation Set Items
- Distilling Flasks — round-bottom flasks with a long neck for boiling the liquid.
- Aluminium Condenser Clamp — a four-prong powder-coated aluminium clamp with steel rod for holding the condenser.
- Rubber Tubing — flexible tubing for the cooling-water connections.
See the full School Lab Equipment range.
Request a Quote
Quotes come direct from the manufacturer. Use the Add To Cart enquiry button on this page, or send the quantity (minimum 10 units), the joint type you need, and your delivery location through the contact page.
Last updated: 4 October 2026
