Liebig Condenser for Distillation of Water Manufacturer,Supplier and Exporter in India
Product Code : EL-CL-13490
Jlab Export is a leading Liebig Condenser for Distillation of Water Manufacturer,and suppliers in India
Liebig Condenser for Distillation of Water (code EL-CL-13490) is a 450 mm straight-tube condenser in molybdenum glass with a 14/29 joint size, used to turn hot vapour back into liquid during distillation so the distillate is collected instead of escaping as steam. Cooling water flowing through the outer jacket takes heat from the vapour in the inner tube. JLab manufactures this condenser in Ambala, India (model JL/IPL-821).
Specifications
| Parameter | Detail |
|---|---|
| Model | JL/IPL-821 |
| Material | Molybdenum glass |
| Length | 450 mm |
| Joint size | 14/29 |
| Use | Distillation, reflux and purification |
| Quality check | Each condenser is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 50 units |
| Dispatch time | Usually 3–5 working days |
| Product code | EL-CL-13490 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Connecting the Cooling Water
Clamp the condenser sloping down from the still head to the receiver. Connect the water supply to the lower inlet and run the outflow from the upper outlet, so the cooling water travels up the jacket against the downward flow of vapour. Filling from the bottom keeps the jacket full with no air pocket, and the coldest water meets the condensate just before it leaves, which gives the most complete condensation. Start the water before heating and keep it running until the flask has cooled.
Distilling Water
Steam from water boiling in the flask passes into the inner tube, gives up its heat through the glass wall and runs down into the receiver as distilled water, while dissolved salts stay behind in the flask. The same condenser can also be mounted upright above a flask for reflux, returning the condensed vapour to the boiling liquid.
Related Distillation Items
- Round-bottom Flask — round-bottom flask with a 14/29 section to match the condenser.
- Flask Electric Heater — electric heater whose woven glass yarn basket wraps around the flask.
- Liebig Condenser — shorter glass Liebig condenser for general laboratory use.
Distillation glassware and heating apparatus are in the Chemistry Lab range.
Request a Quote
Place an order through Add To Cart, or ask for a quotation on the contact page with the number of condensers and your delivery address.
