Multi-Head Mini Split Heat Pump Training Unit Manufacturer,Supplier and Exporter in India

Product Code : EL-TWL-13134
Jlab Export is a leading Multi-Head Mini Split Heat Pump Training Unit Manufacturer,and suppliers in India

One outdoor unit drives two indoor units on this two-zone mini split heat pump trainer. Zone 1 has a high wall unit and zone 2 a ceiling cassette. The ductless R-410A system is mounted on an aluminium frame. It has expanded view sight glasses at key points, high and low side service ports and switches for setting electrical faults.

Specifications

System	Two-zone ductless mini split heat pump on an aluminium frame
Indoor units	Zone 1 high wall unit, zone 2 ceiling cassette
Refrigerant	R-410A
Power supply	220–240 V, 50 Hz
Observation	Expanded view sight glasses at key points in the system
Service ports	Accessible high and low side ports
Fault simulation	Electrical faults set by switches
Airflow control	Louver controlling the air flow to the outdoor unit
Display	TV display screen
Supplied with	Instructor booklet with lab manual, instructor guide and operation guide, manifold service kit
Minimum order quantity	1 unit
Dispatch time	Usually 14–18 working days
Manufacturer	JLab (Jain Laboratory Instruments Pvt Ltd), Ambala, India

Practicals with the Two-Zone Heat Pump

Students first run each zone on its own, then both together, in cooling and in heating. At the service ports they read high and low side pressures with Manifold Gauges for Air Conditioning, which carry an R-410A scale. A Digital Psychrometer at the return and supply air of each indoor unit gives dry bulb, wet bulb and humidity. The class then compares the wall unit with the cassette.

The louver on the outdoor unit makes a simple airflow test. Partly closing it in cooling mode starves the outdoor coil of air, and students watch the high side pressure climb. In heating mode the same restriction lowers the low side pressure. The teacher then sets electrical faults with the switches, and students trace each one with a Digital Clamp Meter and the lab manual.

Frequently Asked Questions

What does two-zone mean on a mini split?
One outdoor unit serves two indoor units, and each indoor unit heats or cools its own room or zone. Here zone 1 is a high wall unit and zone 2 a ceiling cassette, so two common indoor types can be studied on one system.

How does the heat pump switch from cooling to heating?
A reversing valve swaps the jobs of the coils. In cooling the indoor coils absorb heat as evaporators. In heating they give out heat as condensers, while the outdoor coil takes heat from the outside air.

Which refrigerant and gauges does it use?
It runs on R-410A, so use a manifold with an R-410A scale on the high and low side service ports. R-410A works at higher pressures than older refrigerants and, being a blend, is charged as a liquid.

What faults can students practise on?
Electrical faults are set with switches on the unit. Students find each one with meters, while the lab manual and instructor guide support the teacher during the exercises.

What are the expanded view sight glasses for?
They show the state of the refrigerant at key points. Students see liquid, vapour or a bubbling mix and link what they see to the pressures on the gauges in each operating mode.
