Penetration of Bituminous Material, Grease, Petrolatum, Waxes, Gel Manufacturer,Supplier and Exporter in India
Product Code : EL-MLE-13266
Jlab Export is a leading Penetration of Bituminous Material, Grease, Petrolatum, Waxes, Gel Manufacturer,and suppliers in India
Penetration of Bituminous Material, Grease, Petrolatum, Waxes, Gel (code EL-MLE-13266) is a penetrometer that measures how far a penetrating body sinks into a semi-solid sample, read on a calibrated dial of 360 divisions of 1/10 mm. It has a timer-controlled release and a 47.5 g plunger, and is built for the bitumen, grease, petrolatum, wax and gel methods in the table. JLab manufactures this dial penetrometer in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Test methods | ASTM D5, D217, D937, D1321, D1403, D2884; IP 49, 50, 179, 310, 376; DIN 51579, 51580, 51804, 52010 |
| Dial | Calibrated, 360 divisions of 1/10 mm, with release button |
| Release and timing | Release controlled by a timer; check light for movements |
| Column and plunger | Stainless steel |
| Head | Analytical head with calibre for millimetre measurement; steel sliding bar with safety brake |
| Manual release | Lever system for the penetration weight |
| Plunger/slider | 47.5 g, included |
| Base | Metallic, with inset spirit level and adjustable feet |
| Other parts | Adjustable viewing mirror; stainless steel container centring device |
| Size and weight | 35 × 30 × 70 cm (L × W × H); 9 kg |
| Quality check | Each penetrometer is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-MLE-13266 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Reading Penetration in Tenths of a Millimetre
Penetration expresses the consistency of a semi-solid as the depth, in tenths of a millimetre, to which the needle or cone named in the method sinks vertically into the sample under a fixed load, for a fixed time, at a fixed temperature. Each dial division equals 1/10 mm, so the change in dial reading gives the penetration value directly; a harder bitumen or a stiffer grease gives a lower number.
Setting Up a Test
Level the base with the inset spirit level and adjustable feet, centre the sample container with the stainless steel centring device, and use the adjustable viewing mirror to bring the tip just onto the sample surface. Pressing the release button frees the penetration weight for the time set on the timer, and the lever system gives a manual release instead. The analytical head travels on a steel sliding bar fitted with a safety brake.
Other Bitumen and Petroleum Test Apparatus
- Ring and Ball — softening point of bitumen in a heated bath with motor stirrer.
- Standard Tar Viscometer — copper-bath cup viscometer for cut-back bitumen and road oil.
- Cloud and Pour Point — refrigerated two-compartment cloud and pour point tester for petroleum products.
The penetrometer is listed in Mechatronics Lab Equipments, within Mechanical Engineering Lab Equipment.
Request a Quote
Send an enquiry with Add To Cart, or tell us through our contact page the quantity, the materials you will test and the delivery town.
