Reciprocating Compressor (Actual Cut Section) Manufacturer,Supplier and Exporter in India
Product Code : EL-RAACL-10093
Jlab Export is a leading Reciprocating Compressor (Actual Cut Section) Manufacturer,and suppliers in India
Reciprocating Compressor (Actual Cut Section) (code EL-RAACL-10093) is a piston-type compressor of the kind used in refrigeration and air conditioning, made from original parts and sectioned to show its internal construction. It is painted, set on a metal or wooden base and supplied with a key card and literature on how it works. JLab produces this sectioned piston compressor in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Type | Reciprocating (piston-type) compressor, actual cut section |
| Built from | Original parts, sectioned to reveal the internal construction |
| Finish | Painted |
| Mounting base | Metal or wooden |
| Supplied with | Key card and literature on how it works |
| Quality check | Each cut-section model is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 14–18 working days |
| Product code | EL-RAACL-10093 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How a Reciprocating Compressor Works
A crank turns the rotary motion of the motor into the to-and-fro stroke of a piston in its cylinder. On the suction stroke, the pressure in the cylinder falls below the suction line pressure and the suction valve opens to let refrigerant vapour in. On the compression stroke both valves stay shut until the cylinder pressure exceeds the discharge line pressure, when the discharge valve opens and the hot, high-pressure vapour leaves for the condenser. A little gas stays behind in the clearance space and re-expands at the start of each suction stroke, which is why volumetric efficiency falls as the pressure ratio rises.
Other Compressor and Refrigerator Cut Sections
- Rotary Compressor (Actual Cut Section) — sectioned rotary compressor for comparing the two ways of compressing vapour.
- Reciprocating Hermetic Compressor — colour-coded cut-out hermetic compressor, belt driven and turned by a handle.
- Domestic Refrigerator (Actual Cut Section) — sectioned household refrigerator made from original parts.
These models are grouped in Refrigeration and Air Conditioning Lab within Engineering Lab Equipment.
Request a Quote
Buy through Add To Cart or contact us on the contact page; include the quantity and the delivery address, and say whether a metal or wooden base suits you.
