Binocular Upright Metallurgical Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-987
Jlab Export is a leading Binocular Upright Metallurgical Microscope Manufacturer,and suppliers in India
Binocular Upright Metallurgical Microscope (code EL-M-987) is a two-eyed reflected-light microscope for polished metal surfaces, combining a 45° binocular head with achromatic M4X, M10X and M40X objectives and two eyepiece powers chosen from H6X, WF10X and H16X. It is one of the metallurgical microscopes JLab manufactures in Ambala.
Specifications
| Parameter | Detail |
|---|---|
| Head | Binocular, inclined at 45° |
| Focusing | Coaxial focusing knobs on both sides |
| Nosepiece | Quadruple revolving, with centring and positive click stops |
| Stage | Large coaxial mechanical stage, X-Y movement |
| Illumination | Bright field vertical illuminator, 6 V, 20 W halogen |
| Illuminator controls | Field diaphragm, filter slots, bulb centring mechanism |
| Objectives | Achromatic DIN M4X, M10X and M40X |
| Eyepieces | H6X, WF10X, H16X (any two) |
| Quality check | Each microscope is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 5 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-M-987 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Picking the Eyepiece Pair
Any two of the three eyepiece powers can be supplied. Across the M4X to M40X objectives, H6X covers 24X–240X, WF10X covers 40X–400X and H16X covers 64X–640X, so the H16X carries detail furthest and the H6X gives the widest overview of a polished section.
Light Path and Controls
The vertical illuminator sends light from its 6 V, 20 W halogen bulb down through the objective onto the specimen, which reflects it back up to the binocular head. A field diaphragm trims the illuminated area, filter slots hold colour filters, and the centring mechanism aligns the bulb. Coaxial focusing knobs on both sides and a large coaxial stage complete the stand.
Other Upright Metallurgical Models
- Monocular Upright Metallurgical Microscope — monocular version with the same field-diaphragm illuminator and objectives.
- Trinocular Upright Metallurgical Microscope — trinocular version offering the same three eyepiece powers.
- Halogen Bulb 6 Volts, 20 Watts — bi-pin halogen bulb rated at 6 volts and 20 watts.
See Microscope, under Microscope Lab Equipment, for monocular, binocular and trinocular versions side by side.
Request a Quote
Choose Add To Cart, or message us on the contact page with the eyepiece pair you prefer, the quantity and the delivery destination.
