Trinocular Upright Metallurgical Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-988
Jlab Export is a leading Trinocular Upright Metallurgical Microscope Manufacturer,and suppliers in India
Trinocular Upright Metallurgical Microscope (code EL-M-988) is an upright reflected-light microscope with a 45° trinocular head, so a camera can sit on the third tube while both eyes stay at the eyepieces. It uses achromatic M4X, M10X and M40X objectives and a 6 V, 20 W halogen vertical illuminator with a field diaphragm. Each unit is manufactured by JLab in Ambala, Haryana.
Specifications
| Parameter | Detail |
|---|---|
| Head | Trinocular, inclined at 45° |
| Focusing | Coaxial focusing knobs on both sides |
| Nosepiece | Quadruple revolving, with centring and positive click stops |
| Stage | Large coaxial mechanical stage, X-Y movement |
| Illumination | Brightfield vertical illuminator, 6 V, 20 W halogen |
| Illuminator controls | Field diaphragm, filter slots, bulb centring mechanism |
| Objectives | Achromatic DIN M4X, M10X and M40X |
| Eyepieces | H6X, WF10X, H16X (any two) |
| Quality check | Each microscope is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 5 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-M-988 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Reflected-Light Imaging in an Upright Stand
The specimen lies polished side up and the objectives view it from above. Light from the halogen bulb passes through the vertical illuminator and down the objective, and the opaque metal reflects it back through the same objective into the head. The field diaphragm limits the lit patch to what is being viewed, which keeps glare from a mirror-like polish under control.
Eyepiece and Magnification Choices
Two eyepiece powers are chosen from H6X, WF10X and H16X. With the three objectives, H6X gives 24X, 60X and 240X; WF10X gives 40X, 100X and 400X; and H16X gives 64X, 160X and 640X. Both-side coaxial focusing knobs and a large coaxial stage handle the specimen.
Related Trinocular and Upright Models
- Binocular Upright Metallurgical Microscope — binocular version with the same eyepiece choice and illuminator.
- Universal Trinocular Metallurgical Microscope — trinocular model with field and aperture diaphragms and a P7 eyepiece.
- Blue Filter Metallurgical Microscope — daylight blue filter that offsets the yellow tone of halogen lamps.
Further reflected-light and biological instruments are in Microscope as part of Microscope Lab Equipment.
Request a Quote
Press Add To Cart or contact us through the contact page; mention your two eyepiece powers, the number of microscopes and the delivery point.
