CNC Lathe Trainer Manufacturer,Supplier and Exporter in India
Product Code : EL-CLE-9030
Jlab Export is a leading CNC Lathe Trainer Manufacturer,and suppliers in India
CNC Lathe Trainer (code EL-CLE-9030) is a training lathe with a 250 mm swing over the bed, 450 mm between centres and a 135 mm wide bed, powered by a brushless motor and controlled from a computer through CNC software. Ball leadscrews driven by stepper motors give the longitudinal and cross feeds. The trainer lathe is produced by JLab in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Swing over bed | 250 mm (10 in) |
| Swing over apron | 110 mm (4.3 in) |
| Distance between centres | 450 mm (18 in) |
| Bed width | 135 mm (5.3 in) |
| Feeds | Longitudinal and cross, by ball leadscrews and stepper motors |
| Tool post | 4-way |
| Motor | Brushless |
| Machine size (L x W x H) | 1370 x 700 x 1450 mm |
| Packing size (L x W x H) | 1570 x 980 x 1685 mm |
| Weight (net / gross) | 420 / 490 kg |
| Quality check | Each lathe trainer is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 14–18 working days |
| Product code | EL-CLE-9030 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Swing, Centres and Work Size
Swing over the bed, 250 mm, is the maximum diameter that turns clear of the bed, while swing over the apron, 110 mm, is the maximum that clears the carriage, so long work passing over the carriage is limited to the smaller figure. Distance between centres, 450 mm, sets the longest work that can be supported between centres.
Tool Post, Door Lock and Control
The 4-way tool post holds up to four tools, any of which can be swung round to the work. The machine also has an automatic safety door lock, a work light and an additional power socket for the computer, and its control provides automatic diagnosis and power cut-off protection for the program.
Other CNC Lathe Trainers and Machines
- CNC Lathe Machine — heavier lathe with gang tool carriage, coolant pump and thread function.
- CNC Lathe Trainer Stepper — trainer offered with flat or slant bed and PLC-based control.
- CNC Trainer Lathe Machine — trainer lathe with a linear turret and LM guide ways.
- CNC Lathe Machine Trainer — PC-based trainer with hand wheel, linked to the PC by network cable.
Browse CAD/CAM Lab Equipments in Mechanical Engineering Lab Equipment for more.
Request a Quote
Quotations for the lathe trainer come through Add To Cart or the contact page; tell us the quantity and the full shipping address.
