Digital/Analogue Oscilloscope Manufacturer,Supplier and Exporter in India
Product Code : EL-MI-4922
Jlab Export is a leading Digital/Analogue Oscilloscope Manufacturer,and suppliers in India
Digital/Analogue Oscilloscope (code EL-MI-4922) is a 40 MHz, two-channel oscilloscope that works both as a live analogue scope and as a digital scope that captures and measures signals — two oscilloscopes in one. It is used in electronics, communication and physics labs of engineering colleges, polytechnics and ITI/TVET institutes, with 5 mV/div to 20 V/div sensitivity and an RS232 link to a PC. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Bandwidth | 40 MHz |
| Channels | 2 |
| Sensitivity | 5 mV/div to 20 V/div |
| Operating modes | CH1, CH2, XY, CHOP, ALT (auto), ADD, −CH2, MULT |
| Sweep speed (analogue) | 50 ns/div to 200 ms/div |
| Sweep speed (digital) | 10 ns/div to 200 s/div |
| Special triggering | TV lines and frames |
| Trigger sensitivity | Internal 0.5 to 1 div; external 100 to 200 mV |
| Sample rate | Single shot 50 MS/s; ETS (equivalent-time sampling) 10 GS/s |
| Measurements | 17 automatic measurements; cursor measurements of voltage, time, 1/t (frequency) and phase |
| Other modes | Envelope, triggered roll, digital XY, glitch mode; auto set |
| PC connection | RS232 digital serial link; SCPI programming; PC and printer drivers |
| Safety rating (as listed) | 300 V |
| Power supply | 96 V to 264 V, 45 to 440 Hz |
| Supplied with | 1 mains lead, 1 user’s manual and a programming manual |
| Quality check | Each oscilloscope is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-MI-4922 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How Does It Compare with Other JLab Oscilloscopes?
| Model | Bandwidth | Type | Other listed details |
|---|---|---|---|
| This oscilloscope (EL-MI-4922) | 40 MHz | Analogue and digital in one | 2 channels; 50 MS/s single shot; 17 automatic measurements; RS232 and SCPI |
| Dual Trace Oscilloscope | 20 MHz | Analogue, cathode ray tube | Two channels; TV triggering |
| Cathode Ray Oscilloscope | 10, 20 or 30 MHz versions | Analogue CRO | For general physics and electronics labs |
Choose this model when students need both a live analogue trace and digital capture, automatic measurements and a PC link in one instrument; the analogue CRO models suit basic waveform display at lower bandwidths.
What Is the Digital/Analogue Oscilloscope Used For?
An oscilloscope draws a voltage against time so students can see a signal’s shape and measure its amplitude, frequency, phase and rise time. In analogue mode the trace is live, which suits adjusting circuits such as amplifiers, oscillators and rectifiers in electronics practicals. In digital mode the scope stores what it captures: a single 50 MS/s shot records a one-off event such as a switch bounce or a pulse, while equivalent-time sampling reaches 10 GS/s on repetitive signals. XY mode draws Lissajous figures for frequency and phase comparison, and TV line and frame triggering locks onto video signals in communication labs.
The 17 automatic measurements and the cursors speed up readings, and the RS232 link with SCPI programming lets a PC control the scope and transfer data for lab reports. Typical users are electronics and communication engineering labs, physics departments and electronics trades in ITI/TVET workshops. Keep the input within the listed 300 V safety rating, use suitable probes, and let the instrument ventilate freely.
What to Specify When Ordering
- Mains supply — the oscilloscope accepts 96 V to 264 V at 45 to 440 Hz; tell us your plug type.
- Probes and accessories — the listing names a mains lead and manuals; list any probes or cables you need.
- PC connection — say if you will use the RS232 link and printer or PC drivers.
- Quantity — the minimum order is 10 units.
Frequently Asked Questions
What bandwidth and how many channels does it have?
40 MHz and two channels, with a sensitivity of 5 mV/div to 20 V/div and modes including CH1, CH2, XY, CHOP, ALT, ADD, inverted CH2 and MULT.
What does “digital/analogue” mean on this oscilloscope?
It works as two oscilloscopes in one. The analogue mode gives a live trace at 50 ns/div to 200 ms/div; the digital mode samples and stores signals at 10 ns/div to 200 s/div, with single-shot capture at 50 MS/s.
Can it be connected to a computer?
Yes. It has an RS232 digital serial link, supports SCPI programming and is listed with PC and printer drivers.
What measurements can it make automatically?
Seventeen automatic measurements, plus cursor measurements of voltage, time, frequency (1/t) and phase. An auto set function sets up the display for a new signal.
Which mains supply does it need?
96 V to 264 V at 45 to 440 Hz, so it suits single-phase mains in most countries. A mains lead is supplied.
Are probes included?
The listing names a mains lead, a user’s manual and a programming manual. Probes are not mentioned, so add them to your enquiry if you need them.
Who manufactures this oscilloscope?
Jain Laboratory Instruments Pvt Ltd, trading as JLab, makes it at its works in Ambala, Haryana, India.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, an electronics and scientific laboratory equipment manufacturer in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. This oscilloscope is supplied from JLab’s own works rather than through a trader, so colleges, institutes, dealers and importers buy it factory-direct, each instrument is visually inspected before dispatch, and accessories and repeat orders are handled by the maker. JLab exports worldwide and ships to buyers in every region — for example Malaysia in Southeast Asia, Croatia in Southern Europe, Jordan in the Middle East, Ghana in West Africa and Canada in North America. Tender details are on the JLab lab tenders page.
Oscilloscopes and Instruments to Use With It
- Dual Trace Oscilloscope — a 20 MHz two-channel analogue CRT oscilloscope.
- Cathode Ray Oscilloscope — analogue CRO versions for general physics and electronics labs.
- Digital Storage Oscilloscope 40MHz — a digital storage oscilloscope with two channels plus external trigger.
- 2 Channel Digital Strain Meter — its analogue dynamic output can be viewed on an oscilloscope.
Browse the Electronics Lab Equipments range, or the Measuring Instruments section of the Indian Instruments range.
Request a Quote
Quotes come direct from the manufacturer. Use the Add To Cart enquiry button on this page, or send the quantity (minimum 10 units), the probes and accessories you need, and your delivery location through the contact page.
