Electricity EL2+ "Electrostatics, Magnetostatics, Induction, Lorentz Force" set Manufacturer,Supplier and Exporter in India
Product Code : EL-PL-13531
Jlab Export is a leading Electricity EL2+ "Electrostatics, Magnetostatics, Induction, Lorentz Force" set Manufacturer,and suppliers in India
Electricity EL2+ "Electrostatics, Magnetostatics, Induction, Lorentz Force" set (code EL-PL-13531) is a boxed student set for 21 experiments that run from magnetic poles and field lines through electrostatic charge to induction, Lenz’s law, transformers, generators and the DC motor. Two coils on a U-shaped core, AlNiCo magnets and an electroscope are at its centre. JLab, Ambala, India, makes the EL2+ set.
Specifications
| Parameter | Detail |
|---|---|
| Experiments | 21, on magnetism, electrostatics and induction |
| Magnetic parts | Cylindrical AlNiCo magnets; metal rod; metal washers in box; iron filings in sprinkler; platform for visualizing field lines; pivot bearing; needle holder |
| Coils and core | Coil with 200/400 windings; coil with 300/600 windings; U-shaped core with yoke |
| Electrostatics | Electroscope; acrylic rod; PVC rods; wool fabric; silk fabric |
| Induction rings | Closed aluminium ring; open aluminium ring |
| Circuit parts | Incandescent lamp on base; battery holder with 3 AA batteries; multi-purpose base; socket base; connecting wires, 25 cm, red and blue |
| Required accessories | Low-voltage power supply (as for OG1); 2 analog multimeters and 2 x 9 V batteries (as for EL1) |
| Literature | EL2 student workbook and teacher’s manual, in electronic form |
| Storage | Stackable case with captive lid, hinged handle, bayonet lock and foam insert |
| Quality check | Each electricity set is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 4–6 working days |
| Product code | EL-PL-13531 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Experiments in the Set
Magnetism: ferromagnetic materials, magnetic poles, elementary magnetism, magnetic effects, action and reaction between magnets, field lines of magnets and of coils, working and non-working magnetic systems, and a ferromagnetic measuring system. Electrostatics: electrostatic force, the electroscope and the sign of a charge. Induction and forces: two experiments on electromagnetic induction, the Lorentz force, Lenz’s law, self-induction, transformer laws, alternating-current generators, the DC motor and eddy currents.
Rings, Coils and Turns Ratios
Switching a coil’s current on or off makes the closed aluminium ring kick, because the current induced in it opposes the change in magnetic field; the open ring cannot carry a circulating current and barely moves. That is Lenz’s law in one step. With the 200/400 and 300/600 windings on the U-core and yoke, the transformer experiments show the output-to-input voltage ratio following the turns ratio. Rubbed with the wool or silk cloth, the acrylic and PVC rods charge the electroscope, so the sign of each charge can be compared.
Related Electricity and Magnetism Apparatus
- EL1 Electricity Box, Electrical Circuits — first circuits set, used with the same analog multimeters and 9 V batteries.
- EL4 "Lorentz Force" Electricity Set — set of 6 Lorentz-force experiments with conductor plates and a coil.
- Apparatus to Demonstrate Faraday’s Law and Lenz’s Law — guide tube, copper collar and neodymium magnet for Lenz’s law.
- Iron Filings — jar of filings with a shaker lid, for tracing field lines.
Other magnetism and induction apparatus sits under Physics Lab.
Request a Quote
Use Add To Cart or the contact page for EL2+ sets: give the quantity, say whether the EL1 meters and batteries are needed too, and name the delivery town.
