Clamp-on-Ampere Meter Manufacturer,Supplier and Exporter in India
Product Code : EL-LE-11722
Jlab Export is a leading Clamp-on-Ampere Meter Manufacturer,and suppliers in India
Clamp-on-Ampere Meter (code EL-LE-11722) is a true-RMS clamp meter, model JL127/012, that reads AC current up to 600 A through a 30 mm jaw without breaking the circuit, and also measures AC and DC voltage to 600 V, resistance, capacitance, frequency, duty cycle and temperature. JLab makes this clamp meter in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Model | JL127/012 |
| AC current | 600 A, accuracy 1.8% ±5 |
| AC and DC voltage | 600 V, accuracy 1.5% ±5; DC mV range |
| Resistance | 4000 Ω, accuracy 1.5% ±5 |
| Continuity | Buzzer at ≤ 70 Ω |
| Temperature | 0–400 °C |
| Display | 6000 count, backlit LCD, refreshed 2 times per second |
| Jaw opening | 30 mm |
| Measurement category | CAT III 600 V |
| Power and size | 2 AAA batteries; 207 × 75 × 34 mm |
| Quality check | Each clamp meter is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 5 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-LE-11722 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Taking a Current Reading
Close the jaw around one conductor only; clamping a whole cable with live and neutral together cancels the field and reads close to zero. True-RMS measurement keeps the reading correct on the distorted waveforms drawn by drives and electronic loads, peak hold catches the surge when a motor starts, and data hold freezes the value so it can be read after the jaw is removed. Ranging is automatic or manual, the 6000-count display reads to 3 5/6 digits, and diode and continuity tests are built in.
Related Electrical Meters
- Multimeter Digital — for currents up to 10 A measured in series.
- Insulation Tester — insulation checks on the same motors and cables.
- Earth Tester (Complete Set) — earth resistance tests for the installation.
- True RMS General Purpose Clamp Meter — another true-RMS clamp meter from the instrument range.
Meters and testers for electrical work are grouped in Lab Equipment.
Request a Quote
Send the number of clamp meters and the delivery location through Add To Cart or the contact page.
