LCD Screen Digital Handheld Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-8137
Jlab Export is a leading LCD Screen Digital Handheld Microscope Manufacturer,and suppliers in India
LCD Screen Digital Handheld Microscope (code EL-M-8137) is a battery-powered digital microscope with its own 3-inch LCD screen, so the magnified image is viewed on the unit itself. It magnifies 10x–300x optically, reaches 1200x with digital zoom, records on a 5-megapixel sensor and lights the subject with 8 dimmable LEDs. JLab manufactures this handheld LCD model in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Display | 3-inch LCD screen |
| Magnification | 10x–300x optical; up to 1200x with 4x digital zoom |
| Image sensor | 5 megapixels |
| Still/video capture resolution | 12M, 9M, 5M, 3M, 1.3M, VGA |
| Frame rate | Max 30 f/s at 600 lux brightness |
| Focus | Manual, 10–50 mm |
| Illumination | 8 LEDs with light intensity control |
| Storage and output | MicroSD card slot (up to 32 GB SDHC); TV output |
| Power | 800 mAh rechargeable Li-ion battery, 3.5–4 hours standalone working time |
| Weight | 0.88 lb |
| Quality check | Each microscope is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 5 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-M-8137 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Working with the Handheld Microscope Away from the Bench
The rechargeable 800 mAh battery gives 3.5–4 hours of use without a cable, so the microscope can be taken to the object being examined instead of the object being brought to a bench. Focus is set by hand over a 10–50 mm range, and the LED brightness is turned up or down to suit the subject. Stills and video clips are saved to a microSD card of up to 32 GB, and the TV output lets the live picture be shown on a television for a group.
Optical Range and Digital Zoom
Up to 300x the enlargement comes from the lens itself; beyond that the 4x digital zoom enlarges the sensor image to a maximum of 1200x. Digital zoom makes features look bigger on the screen but does not resolve finer detail than the optical setting, so most observation and photography is done within the optical range. Capture size can be chosen from VGA up to 12M to balance image detail against card space.
Related Digital Microscopes
- Stand Alone LCD Screen Digital Microscope — larger 3.5-inch LCD model for sharing observations with others.
- 1080P Full HD Wi-Fi Digital Microscope — shows its Full HD image on a phone or tablet over Wi-Fi.
- USB Digital Microscope with 2MP Camera — USB model with a 2 MP image sensor and an adjustable stand.
Bench, stereo and digital models are grouped under Microscope, part of the wider Microscope Lab Equipment section.
Request a Quote
Use Add To Cart to start an order, or write to us through the contact page with the number of microscopes and the delivery city and country.
