Pulley Set with Hooks Manufacturer,Supplier and Exporter in India
Product Code : EL-CL-13434
Jlab Export is a leading Pulley Set with Hooks Manufacturer,and suppliers in India
Pulley Set with Hooks (code EL-CL-13434) is a double tandem pulley block: two 3 cm black plastic wheels turning on bearings in a metal frame, with a hook at each end for hanging the block and attaching a load. It is used to demonstrate pulleys, mechanical advantage, force, motion and load lifting. JLab produces this pulley block in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Model | JL/IPL-609 |
| Type | Double tandem pulley block |
| Wheel diameter | 3 cm |
| Wheels | Black plastic, on bearings |
| Frame | Metal |
| Hooks | At both ends |
| Quality check | Each pulley block is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 4–6 working days |
| Product code | EL-CL-13434 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Mechanical Advantage of a Pulley System
In the ideal case, with frictionless pulleys and a weightless rope, the mechanical advantage of a pulley system equals the number of rope sections supporting the moving block. A single fixed pulley gives a mechanical advantage of 1 and only changes the direction of the pull. When this double block is combined with another pulley block, the rope can be threaded so that more sections share the load: the effort falls in proportion, but the rope must be pulled that many times farther than the load rises, so the work done stays the same.
The hooks at both ends let the block serve either as the fixed block, hung from a support, or as the moving block that carries the load. The bearings keep friction low, so the wheels turn smoothly during a run.
Related Pulleys and Loads
- Pulley with Table Clamp — a 4 cm bearing pulley that clamps to a table.
- Single Pulley (Painted) — a single low-friction pulley with a deep V-groove.
- Weights with Hooks — paired hooked masses to serve as the load.
- Mechanical Dynamometer with Upper and Lower Hooks — measures the effort on the rope in newtons.
More mechanics apparatus is in the Chemistry Lab range.
Request a Quote
Use Add To Cart or the contact page to request pulley blocks; tell us the quantity and the delivery town.
Last updated: 29 October 2026
