Tap & Die Set, Metric Small Manufacturer,Supplier and Exporter in India

Tap & Die Set, Metric Small

Product Code : EL-CLE-9093
Jlab Export is a leading Tap & Die Set, Metric Small Manufacturer,and suppliers in India

Taps cut internal threads in drilled holes, and dies cut external threads on rod. This HSS set covers seven metric sizes from 6 to 12 mm. It has taper, second and bottoming taps, circular split dies, die stocks and tap wrenches, all in a fitted case.

Specifications

Metric sizes6, 7, 8, 9, 10, 11 and 12 mm
MaterialHSS (high speed steel)
TapsTaper, second and bottoming
DiesCircular, split pattern
Also includedDie stocks and tap wrenches
CaseFitted case
Minimum order quantity10 units
Dispatch timeUsually 4–6 working days
ManufacturerJLab (Jain Laboratory Instruments Pvt Ltd), Ambala, India

Workshop Practice: Drilling, Tapping and Threading

A standard ITI job is to drill and tap a hole in a mild steel plate. Students mark the centre with the Punch Tool, drill the tapping size and hold the plate in the Bench Vice. They run the taper tap in, checking with an Engineers Square that it stands upright. The second tap follows, and the bottoming tap finishes a blind hole.

Threading a rod is the matching exercise. A length of round bar is chamfered at the end, gripped upright in the vice and threaded with the split die in its stock. Students then screw the rod into their own tapped plate to check the fit.

Frequently Asked Questions

In what order are the three taps used?
Start with the taper tap, which has a long lead and finds its way in square. Follow with the second tap. Use the bottoming tap last, only where the thread must run to the bottom of a blind hole.

What size should the hole be drilled before tapping?
For a metric thread, the tapping drill is close to the thread size minus the pitch. Check the pitch of the thread you need, then pick the drill from a tapping size chart before you mark out.

Can the set repair a damaged thread?
Yes, when the damage is light. Run the matching tap through a burred nut or tapped hole, or run the die over a bruised bolt thread, by hand and with oil. Start it carefully so it follows the old thread and does not cut a new one. A badly stripped thread needs a new part.

Do taps and dies need cutting oil?
Use cutting oil when threading steel. It cools the tap, gives a cleaner thread and lets the tap turn more easily. Brass and cast iron are usually cut dry.

Why turn the tap back every so often?
Turning back about a quarter turn after each half turn forward breaks the chip. Chips that are not broken pack the flutes, the tap binds, and a small tap can snap in the hole.

Other Thread Cutting and Drilling Tools

For a quote, use Add To Cart or send us a message through the contact page.
