Triple Scale DC Voltmeter Manufacturer,Supplier and Exporter in India
Product Code : EL-GLE-8596
Jlab Export is a leading Triple Scale DC Voltmeter Manufacturer,and suppliers in India
Triple Scale DC Voltmeter (code EL-GLE-8596) is an easy-reading moving coil voltmeter on a sturdy base, with three ranges — 0–3 V, 0–15 V and 0–300 V — for measuring DC potential difference in school and college electricity practicals. It has 4 mm socket terminals and an accuracy of ±2.5%. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Measures | DC voltage (potential difference) |
| Ranges | 0–3 V, 0–15 V and 0–300 V (triple range) |
| Movement and accuracy | Moving coil, ±2.5% |
| Terminals | 4 mm sockets |
| Scale length | About 65/70 mm |
| Deflection angle | 90° |
| Overall size | 100–140 mm x 100 mm x 90–100 mm |
| Base | Sturdy base; easy-reading scale |
| Quality check | Each voltmeter is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-GLE-8596 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How Does It Compare with Other JLab Voltmeters?
| Voltmeter | Ranges | Other details from each product page |
|---|---|---|
| Triple Scale DC Voltmeter (EL-GLE-8596) | 0–3 V, 0–15 V, 0–300 V | Moving coil, ±2.5%; 4 mm sockets; scale about 65/70 mm |
| Voltmeter Triple Range 0-3 and 0-15 and 0-30V DC JLab | 0–3 V, 0–15 V, 0–30 V | Fully encased plastic body; 75 mm scale; ±2.5%; zero adjustment screw; overload protection |
| Voltmeter Double Range 0-1.5 and 0-15V DC JLab | 0–1.5 V, 0–15 V | Fully encased plastic body; 75 mm scale; ±2.5%; zero adjustment screw; overload protection |
Choose this voltmeter when a bench needs a 0–300 V range as well as 0–3 V and 0–15 V. The 0–30 V triple-range meter tops out lower, and the double-range meter has a 0–1.5 V range for lower readings.
What Is the Triple Scale DC Voltmeter Used For?
A voltmeter is connected across a component, in parallel, to show the potential difference between its two ends. In a moving coil meter the pointer moves in proportion to the current through the coil, and a high series resistance turns this into a voltage reading; this type is for direct current, so the connections must be made the right way round. The 0–3 V scale gives fine readings across a cell or a single resistor, the 0–15 V scale covers typical low-voltage supplies, and the 0–300 V scale handles higher DC voltages. With an ammeter and a rheostat it sets up the current–voltage practical behind Ohm’s law in class 10 science and the resistance and potential-difference experiments of class 12 physics, as well as college electricity labs. The 4 mm sockets take standard 4 mm plug leads.
What to Specify When Ordering
- Number of voltmeters, for example one per practical bench.
- Ammeters, rheostats or connecting wire — separate items that can be quoted on the same enquiry.
Frequently Asked Questions
What ranges does the Triple Scale DC Voltmeter have?
0–3 V, 0–15 V and 0–300 V.
How accurate is it?
It is a moving coil meter with an accuracy of ±2.5%.
Can it measure AC voltage?
No. It is a DC voltmeter of the moving coil type, made for direct current.
Who manufactures the Triple Scale DC Voltmeter?
Jain Laboratory Instruments Pvt Ltd (JLab) makes it at its works in Ambala, Haryana, India, and quotes for it as the manufacturer.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, an Indian manufacturer of electrical measuring instruments and school physics apparatus, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. These voltmeters are produced at JLab’s own works, not bought from a trader, so schools, colleges, dealers and importers order from the maker, and repeat orders are handled by the same manufacturer. JLab holds MSME Udyam registration UDYAM-HR-01-0003849 (manufacturing enterprise) and Importer-Exporter Code 3317504552. JLab exports worldwide and ships to buyers in every region — the UK in Western Europe, New Zealand in Oceania, Colombia in South America, Vietnam in Southeast Asia and Cameroon in Central Africa are a few examples.
Meters and Circuit Parts
- Triple Scale DC Ammeter — a moving coil DC ammeter with milliampere and ampere ranges, on a sturdy base.
- Rheostats (Nichrome Type) — sliding-contact rheostats wound with nichrome wire for varying the current in a circuit.
- Black Single Strand Panel Wire — plastic-coated single-strand wire for connecting components in a circuit.
See the General Lab Equipment range and the Laboratory Supplies section for more.
Request a Quote
Ask for a quotation using the Add To Cart button, or write through the contact page with the number of voltmeters, any ammeters or other circuit parts, and the delivery address.
