Ultrasonic Pulse Velocity Tester Manufacturer,Supplier and Exporter in India
Product Code : EL-M-8892
Jlab Export is a leading Ultrasonic Pulse Velocity Tester Manufacturer,and suppliers in India
Ultrasonic Pulse Velocity Tester (code EL-M-8892) is a battery-operated, microprocessor-based instrument for the non-destructive evaluation of concrete homogeneity and the determination of dynamic elastic modulus. It measures transit times from 0.1 to 1999.9 µs at 0.1 µs resolution and shows results on a 128 x 64 pixel display. Compact, lightweight and portable, it is built by JLab in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Display | Large digital display, 128 x 64 pixel |
| Transit time range | 0.1–1999.9 µs |
| Resolution | 0.1 µs |
| Pulse rate | 1, 2, 5 or 10 per second, selectable |
| Transmitter output | 1200 V |
| Frequency range | 24–150 kHz |
| Receiver input impedance | 1 MΩ |
| Power | Internal rechargeable 2400 mAh battery pack with external charger; 14 working hours at 1 Hz pulse rate |
| Electronics | Microprocessor based, digital calibration, connectable to an oscilloscope |
| Weight | Tester 0.5 kg; complete set 2.3 kg |
| Quality check | Each pulse velocity tester is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 5 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-M-8892 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
What Is a UPV Tester Used For?
Structural engineers, testing laboratories and engineering colleges use it to check concrete quality in slabs, columns, beams and precast units. Transmitting and receiving transducers are placed on opposite faces and the instrument times the pulse passing through; dividing the path length by the transit time gives pulse velocity, and low values point to cracks, voids or poor compaction. Apply couplant at the contact points and recharge the battery after a day of readings.
Frequently Asked Questions
How long does the battery last?
The internal rechargeable 2400 mAh battery pack gives 14 working hours at a 1 Hz pulse rate, and an external charger is used to recharge it.
Can it be connected to an oscilloscope?
Yes. The tester is connectable to an oscilloscope, so the received pulse can be viewed alongside the transit-time reading.
What does it weigh?
The tester itself weighs 0.5 kg and the complete set 2.3 kg, light enough to carry from one test location to the next.
Who makes the Ultrasonic Pulse Velocity Tester?
JLab, the trading name of Jain Laboratory Instruments Pvt Ltd, makes it in Ambala, Haryana, with its other concrete and aggregate testing equipment.
OEM Manufacturer
This tester is manufactured by Jain Laboratory Instruments Pvt Ltd, the Hargolal Road, Ambala firm that trades as JLab and was incorporated in 2017. Engineering colleges and testing laboratories can put it on one quotation with JLab’s other materials-testing apparatus when equipping a concrete laboratory. JLab exports worldwide, including to Thailand in Southeast Asia, the UK in Northern Europe, Spain in Southern Europe and Brazil in South America.
Related Non-Destructive Concrete Testers
- Rebound Hammer — a surface hardness test for concrete or rock strength.
- Concrete Cover Meter — measures the depth of reinforcement in concrete.
- Ultrasonic Flaw Detector — an ultrasonic instrument for detecting internal flaws.
- Compression Testing Machine for Concrete — hand-operated compression testing of concrete.
More testing equipment can be found in Materials, part of Chemistry Lab Equipment.
Request a Quote
To request this tester, use Add To Cart or the contact page and give the quantity, the delivery location and any companion instruments required.
