50MHz Digital Oscilloscope Manufacturer,Supplier and Exporter in India
Product Code : EL-O-10373
Jlab Export is a leading 50MHz Digital Oscilloscope Manufacturer,and suppliers in India
50MHz Digital Oscilloscope (code EL-O-10373) is a four-channel 50 MHz scope sampling at 1 GSa/s, with 12 Mpts of memory that a software key raises to 24 Mpts. FFT, maths functions, mask testing and automatic measurements with statistics are standard, and screen dumps, raw data and set-ups can be stored internally or externally. Made in Ambala, India, this 50 MHz four-channel unit is a JLab product.
Specifications
| Parameter | Detail |
|---|---|
| Bandwidth | 50 MHz |
| Channels | 4 |
| Sample rate | 1 GSa/s |
| Memory depth | 12 Mpts, upgradable to 24 Mpts by software key |
| Waveform capture rate | Up to 30,000 wfms/s |
| Display | 7-inch WVGA (800 x 480) TFT, multi-level intensity grading |
| Standard analysis | FFT, maths functions, mask test, automatic measurements with statistics |
| Interfaces | USB host, USB device, LAN, Aux (trigger out / pass-fail) |
| Options | Real-time waveform record and replay; serial bus trigger and decode (RS232, I2C, SPI) by software key |
| Quality check | Each oscilloscope is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-O-10373 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Mask Testing and FFT on a 50 MHz Scope
A mask test compares each acquired waveform with a tolerance band drawn around a good reference and flags any trace that strays outside it; the Aux output can pass the pass/fail result to other equipment. FFT turns the time record into a frequency spectrum, which helps spot hum, switching noise or a harmonic on a signal that looks clean in the time view. Both come without extra keys on this model.
Storing and Printing Results
Screen images, raw waveform data and instrument set-ups can be saved to internal memory or to external storage, so a lab can keep a reference capture for later comparison. A dedicated front-panel key sends the screen to a compatible printer.
Frequently Asked Questions
Can the memory depth be increased later?
Yes. The scope comes with 12 Mpts of memory, and a software key raises it to 24 Mpts.
Is serial bus decoding included?
RS232, I2C and SPI triggering and decoding are optional functions unlocked by software keys. Real-time waveform record and replay is also an option.
