Beginner Microscope Kit with Digital Camera Manufacturer,Supplier and Exporter in India
Product Code : EL-M-8030
Jlab Export is a leading Beginner Microscope Kit with Digital Camera Manufacturer,and suppliers in India
Beginner Microscope Kit with Digital Camera (code EL-M-8030) is a dual-lit monocular microscope with a digital eyepiece camera that takes the place of the eyepiece to show still images and live video on a computer, using the imaging software supplied. It magnifies 40X, 100X and 400X and comes with an activity guide of experiments. Ambala-based JLab is the maker of this kit.
Specifications
| Parameter | Detail |
|---|---|
| Head | Monocular, inclined at 45°, rotating through 360° |
| Eyepiece | 10X wide field, glass |
| Objectives | 4X, 10X and 40XR (retractable) on a reverse nosepiece; parfocal, parcentred and colour-coded |
| Magnification | 40X, 100X and 400X |
| Camera | Digital eyepiece camera, with imaging software and instructions |
| Illumination | Dual LED, top and bottom, with separate light intensity control |
| Stage | 3.5 in round gliding stage with 360° rotation, locked-on spring-loaded clips and stage stop |
| Diaphragm | 6 hole disc with coloured filters |
| Power | 2 AA batteries (not included) or AC adapter |
| Size and weight | 16 x 10.5 x 7 in; 6 lb |
| Quality check | Each microscope kit is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 5 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-M-8030 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Using the Eyepiece Camera
To put the specimen on screen, take the eyepiece out of the ocular tube and insert the digital eyepiece camera in its place; the computer then shows still images and live video of what is on the stage. The reverse nosepiece turns the objectives away from the viewer, and the 40XR objective has a retractable front that gives way if it meets a slide.
Experiments in the Activity Guide
The activity guide covers hatching brine shrimp, making your own slides, looking at crystals, preparing a mount, creating smears and studying life under glass. Slides of cells, tissues and microscopic organisms are viewed with the bottom light, while rocks, coins, stamps, pond water, insects and flowers are lit from the top. With its white coated plastic body, the scope is light and portable for field study.
Related Beginner and Camera Microscopes
- Digital Eyepiece Camera — Wi-Fi eyepiece camera that streams live images to phones and laptops.
- Beginner Microscope Kit — metal-frame kit microscope with mirror and LED lighting.
- Young Scientist Dual Scope — battery dual scope supplied with a discovery kit of slides and stains.
Find further beginner models in the Microscope category and other optical items across Microscope Lab Equipment.
Request a Quote
Request a quotation for the kit with Add To Cart or through our contact page, adding the quantity and the delivery address.
