Fume Hood Manufacturer,Supplier and Exporter in India
Product Code : EL-ELA-5498
Jlab Export is a leading Fume Hood Manufacturer,and suppliers in India
Fume Hood (code EL-ELA-5498) is a fume cupboard that contains and exhausts toxic or otherwise harmful gases, vapours and mists from chemistry and research work. An inbuilt centrifugal blower keeps the chamber under negative pressure, and the hood has fluorescent lighting, internal electric plugs, gas, vacuum and air connections and a counterbalanced sliding sash. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Type | Laboratory fume hood (fume exhaust hood) |
| Purpose | Contains and exhausts toxic, obnoxious or otherwise harmful gases, vapours and mists |
| Blower | Inbuilt, motor-driven centrifugal blower unit |
| Airflow | Negative pressure in the chamber; contaminated air is extracted from the work area and expelled to the atmosphere, with laboratory air drawn in to sweep out the work chamber |
| Lighting | Fluorescent tubes with safety electrical fittings |
| Electric points | Internally located electric plugs |
| Service connections | Gas, vacuum and air connections |
| Front sash | Counterbalanced sliding up-down front sash (door) |
| Quality check | Each fume hood is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-ELA-5498 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How Does It Compare with Other JLab Fume Hoods?
| Model | Listed construction and sizes | Listed services and options |
|---|---|---|
| This fume hood (EL-ELA-5498) | Inbuilt centrifugal blower; counterbalanced sliding front sash | Fluorescent lighting; internal electric plugs; gas, vacuum and air connections |
| Fume Hood Deluxe Model | Working sizes from 4 x 2 x 2 ft to 8 x 3 x 3 ft | Optional exhaust system, PVC fume duct, storage compartments and FRP or stainless steel lining |
| Junior Fume Hoods | Combined single and double wall construction; counterbalanced tempered glass sash; shipped unassembled, without worktop | Water, gas and electrical service fixtures |
| Fume Hood (150–160 cm wide) | Width 150–160 cm, depth 60–80 cm; 28 in vertical sash | Inbuilt centrifugal blower; electrical services on right or left side |
Choose this fume hood when you want the blower, lighting, electric points and gas, vacuum and air connections built into one unit. The deluxe model is listed in several working sizes with optional ducting and linings, the junior hood ships unassembled for fitting on your own worktop, and the 150–160 cm model gives its width and sash height.
What Is the Fume Hood Used For?
Many routine practicals release fumes that should not be breathed: concentrated acids and ammonia, hydrogen sulphide in salt analysis, organic solvents and the gases from heating or digesting samples. Inside the hood, the blower holds the chamber at a lower pressure than the room, so air flows in through the sash opening, sweeps across the work surface and carries the contaminated air out to the atmosphere instead of into the laboratory. A counterbalanced sash can be raised for setting up apparatus and lowered to narrow the opening during work.
Fume hoods are standard in senior-school chemistry laboratories, where class 11 and class 12 qualitative analysis is carried out, and in college and university chemistry, biochemistry, pharmacy and research laboratories, as well as testing and quality-control labs.
What to Specify When Ordering
- Quantity — the minimum order is 10 units.
- Working size and site details — the space available and where the exhaust will be ducted outside.
- Services — which gas, vacuum, air and electrical points you need at the hood.
- Related items — exhaust blowers, a fume scrubber or safety goggles can be quoted on the same enquiry.
Frequently Asked Questions
What does a fume hood do?
It contains and exhausts toxic, obnoxious or otherwise harmful gases, vapours and mists from the work chamber, so they are carried outside rather than into the laboratory.
How does this fume hood extract the fumes?
A motor-driven centrifugal blower creates negative pressure inside the chamber. Laboratory air is drawn in to sweep out the work chamber, and the contaminated air is expelled to the atmosphere.
Which services are built in?
Fluorescent tube lighting with safety electrical fittings, internally located electric plugs, and gas, vacuum and air connections.
What kind of front sash does it have?
A counterbalanced sliding front sash that moves up and down, so it stays where it is set.
How does it differ from the Fume Hood Deluxe Model?
The deluxe model is listed by working size, from 4 x 2 x 2 ft to 8 x 3 x 3 ft, with optional exhaust system, PVC duct, storage compartments and FRP or stainless steel lining. This hood is described by its built-in blower, lighting, electric plugs and gas, vacuum and air connections.
What should an export enquiry include?
The quantity, destination country and port or city, delivery terms such as FOB or CIF, any packing or labelling needs and the tender reference if applicable.
Who manufactures this fume hood?
Jain Laboratory Instruments Pvt Ltd (JLab) makes it at its works in Ambala, Haryana, India.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, a manufacturer of laboratory apparatus and equipment in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. The fume hood is built at JLab’s own works rather than bought from a trader, so schools, colleges, dealers and importers buy it factory-direct, each unit is visually inspected before dispatch, and repeat orders are handled by the manufacturer. JLab exports worldwide and ships to buyers in every region — for example Taiwan in East Asia, Myanmar in Southeast Asia, Bulgaria in Eastern Europe, Bhutan in South Asia and the USA in North America. Tender information is on the JLab lab tenders page.
Fume Extraction and Lab Safety Items
- Fume Hood Deluxe Model — a fume hood listed in five working sizes with optional ducting and linings.
- Junior Fume Hoods — a hood with a tempered glass sash, shipped unassembled for fitting on an existing worktop.
- Exhaust Blowers — polypropylene centrifugal blowers built for corrosive fume hood applications.
- Fume Scrubber — a polypropylene gas/liquid scrubber for acid and base laden fume streams.
- Safety Goggles — impact- and splash-resistant eye protection for bench work.
See the full Laboratory Fume Hoods range, or browse Educational Laboratory Apparatus and Laboratory Apparatus.
Request a Quote
Ask for a quotation with the Add To Cart enquiry button on this page or through the contact page, giving the number of hoods, the services you need and the delivery destination.
Last updated: 15 October 2026
