LED Illumination Dual Power Binocular Stereo Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-8110
Jlab Export is a leading LED Illumination Dual Power Binocular Stereo Microscope Manufacturer,and suppliers in India
LED Illumination Dual Power Binocular Stereo Microscope (code EL-M-8110) is a binocular stereo microscope with dimmable LED top and bottom lights and fully coated objective pairs of 1X/2X, 1X/3X or 2X/4X, giving 10X/20X, 10X/30X or 20X/40X with paired WF 10X eyepieces. Its left tube has a ±5 diopter adjustment and both tubes move together for eye spacing. JLab fabricates and assembles this LED version at Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Versions | Item 1: 1X/2X objectives, 10X and 20X; Item 2: 1X/3X, 10X and 30X; Item 3: 2X/4X, 20X and 40X |
| Viewing head | Binocular, 45° inclined, 360° rotatable |
| Interpupillary distance | 55–75 mm, synchronized bilateral |
| Diopter adjustment | ±5 on left ocular tube; right tube fixed |
| Eyepieces | Paired WF 10X, setscrew lock; optional WF 15X, WF 20X |
| Optics | Fully coated paired lenses on a rotating turret |
| Working distance | 80 mm |
| Focusing | Heavy-duty rack and pinion with slip clutch; two knobs with tension adjustment; 90 mm range |
| Stage plates | 75 mm frosted glass and 75 mm reversible black/white; spring-loaded clips |
| Illumination | Incident LED top light, diagonally adjustable; transmitted LED bottom light; separate switches and continuous brightness |
| Quality check | Each microscope is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 5 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-M-8110 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Three Versions by Objective Pair
All three versions share the head, stand and lighting; only the objective pair differs. Item 1 with 1X/2X objectives covers 10X and 20X for whole specimens, Item 2 with 1X/3X spans 10X to 30X, and Item 3 with 2X/4X gives 20X and 40X for finer structure. Optional WF 15X or WF 20X eyepieces raise every figure, and setscrews hold the standard pair in place.
Dimmable LED Light From Above and Below
Top and bottom LEDs have separate switches and continuously adjustable brightness, giving transmitted, incident or dual lighting. The diagonally adjustable top LED lights opaque specimens on the black or white face of the reversible plate, while the bottom LED shines through the 75 mm frosted glass plate. The stand is 14 in high on a 7 × 8.75 in base, and its slip-clutch focus has a 90 mm range.
More Dual Power Choices
- Dual Power Binocular Stereo Microscope — same stand, objective pairs and 80 mm working distance
- Dual Power Trinocular Stereo Microscope — trinocular version with halogen top and fluorescent bottom lights
- Dual Power LED Stereo Microscope with Pillar Stand — post-mounted LED dual power model with setscrew-locked eyepieces
Further LED stereo models are under Microscope in Microscope Lab Equipment.
Request a Quote
Quote the item number (1, 2 or 3) and quantity, with your delivery location, when ordering through Add To Cart or our contact page.
Last updated: 29 October 2026
