Logic Gates Experiment Manufacturer,Supplier and Exporter in India
Product Code : EL-DEECP-1161
Jlab Export is a leading Logic Gates Experiment Manufacturer,and suppliers in India
Logic Gates Experiment (code EL-DEECP-1161) is a TTL trainer for verifying the truth tables of the AND, OR, NOT, NAND and NOR gates in digital electronics practicals. A 5 V supply provides the logic 1 and logic 0 levels, TTL ICs supply the AND, OR and NOT gates, and every connection is brought out to sockets on the front panel. Jain Laboratory Instruments Pvt Ltd (JLab) makes it at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Experiment | Verify the truth tables of TTL AND, OR, NOT, NAND and NOR gates |
| Logic supply | 5 V power supply for logic 1 and logic 0 |
| Gate ICs | TTL ICs for AND, OR and NOT gates |
| Construction | Components soldered on the front panel |
| Connections | Brought out at sockets |
| Quality check | Each trainer is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-DEECP-1161 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
What Is the Logic Gates Trainer Used For?
Logic gates are the building blocks of every digital circuit, and verifying their truth tables is usually the first digital electronics practical. Students apply each combination of logic 1 and logic 0 to the gate inputs and record the output: an AND gate gives 1 only when all inputs are 1, an OR gate gives 1 when any input is 1, a NOT gate inverts its input, and NAND and NOR are simply AND and OR followed by inversion. Because the trainer uses TTL ICs on a 5 V supply, logic 0 sits close to 0 V and logic 1 close to the supply voltage, which students can confirm with a multimeter. It suits senior secondary physics practicals where the syllabus covers logic gates, B.Sc. physics and electronics labs, polytechnic courses and ITI electronics workshops.
Frequently Asked Questions
Which gates can be verified on this trainer?
AND, OR, NOT, NAND and NOR. The listing names TTL ICs for the AND, OR and NOT gates; ask JLab how the NAND and NOR experiments are wired on the panel if your practical sheet needs that detail.
What supply does it use for the logic levels?
A 5 V power supply, part of the instrument, provides the logic 1 and logic 0 levels for the TTL gates. State your mains voltage when ordering, as the mains input rating is not given here.
How are connections made?
The components are soldered on the front panel and all connections are brought out at sockets, so students wire each experiment with patch cords instead of handling the ICs.
Who manufactures it?
Jain Laboratory Instruments Pvt Ltd, trading as JLab, at its works in Ambala, Haryana.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, a digital electronics trainer and laboratory equipment manufacturer in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. The logic gates trainer is made at JLab’s own works, not bought from a trader, so schools, colleges, dealers and importers buy it factory-direct, each unit is visually inspected before dispatch, and repeat orders and spares come straight from the manufacturer. JLab exports worldwide and ships to buyers in every region — for example Paraguay in South America, Mauritius in East Africa, Angola in Central Africa, Costa Rica in Central America and the Caribbean and Luxembourg in Western Europe. Tender buyers can use the JLab lab tenders page.
Related Digital Electronics Trainers
- Verification of truth tables of Logic gates using NAND Gate — builds AND, OR, NOR and NOT from NAND gates, showing NAND as a universal gate.
- Verification of Logic Gates and De Morgan Theorems using TTL Logic Gates — adds De Morgan’s theorems to the gate experiments.
- Verification of Boolean Identities and De Morgan Theorems — for checking Boolean expressions with combined gates.
- Digital Trainer to Verify Half Adder using OR, EX-OR and AND Gates — the next step, combining gates into an adder.
See the full Digital Electronic Experiments Computer Principles range or all Scientific Instrument products.
Request a Quote
Quotes come direct from the manufacturer. Use Add To Cart on this page, or send the quantity (minimum 10 units), your mains voltage, any patch cords needed and the delivery location through the contact page.
