Michell Tilting Pad Bearing Apparatus Manufacturer,Supplier and Exporter in India
Product Code : EL-FMAHLE-7334
Jlab Export is a leading Michell Tilting Pad Bearing Apparatus Manufacturer,and suppliers in India
Michell Tilting Pad Bearing Apparatus (code EL-FMAHLE-7334) is a teaching apparatus for the Michell tilting pad bearing, in which the load is carried by several pivoted pads, each running on its own wedge-shaped film of oil. It shows engineering students how this type of bearing builds up the oil film that supports it. The apparatus is built by JLab in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Bearing type | Michell tilting pad bearing |
| Lubrication principle | Hydrodynamic oil film on pivoted pads |
| Quality check | Each bearing apparatus is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 14–18 working days |
| Product code | EL-FMAHLE-7334 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How a Tilting Pad Carries Load
Each pad rests on a pivot and is free to tilt. The moving surface drags oil in under the inlet edge of the pad, and the pad settles at a slight angle so the film is thicker where oil enters than where it leaves. Pressure builds in this converging wedge and supports the load. Because every pad finds its own angle, the wedge adjusts itself to changes in load and speed, unlike a plain journal bearing, where the wedge forms only because the shaft runs off-centre.
Lubrication and Power Transmission Rigs
- Journal Bearing Apparatus — manometer tappings show the oil-film pressure around a loaded plain bearing.
- Slip and Creep Measurement Apparatus — measures power transmitted and belt slip in a pulley drive.
Bearing and drive apparatus can be found in Fluid Mechanics and Hydraulics Lab Equipment, one part of Engineering Lab Equipment.
Request a Quote
Request a quotation via Add To Cart or the contact page, with your quantity and the town for delivery.
