Projection Microscope 2 Manufacturer,Supplier and Exporter in India
Product Code : EL-M-983
Jlab Export is a leading Projection Microscope 2 Manufacturer,and suppliers in India
Projection Microscope 2 (code EL-M-983) is a projection microscope that throws a magnified image of the slide onto a 200 mm graduated screen fitted with a Fresnel lens, covering 125x to 1000x through objectives of 5x, 10x, 20x and 40x. Its 12-volt, 100-watt halogen lamp is workable on 220 V AC. Like its sibling model, it comes from JLab’s own production in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Observation screen | 200 mm, graduated, with built-in Fresnel lens |
| Fittings | Loop and arrow arrangement |
| Stage | Coaxial mechanical |
| Nosepiece | Quadruple revolving |
| Objectives | 5x, 10x, 20x, 40x |
| Magnification | 125x to 1000x |
| Lamp | Halogen, 12 volts, 100 watts |
| Mains supply | 220 V AC |
| Quality check | Each microscope is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 5 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-M-983 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Group Viewing on a 200 mm Screen
Everyone around the bench sees the same projected field, and the graduations on the screen give a shared reference when structures are pointed out or compared. The Fresnel lens built into the screen spreads the light so the picture stays bright toward its edges. A coaxial mechanical stage moves the slide, and the quadruple nosepiece holds all four objectives ready.
Choosing Between Model 2 and Projection Microscopes 1
The two share the same screen, Fresnel lens, objectives, nosepiece, coaxial stage and lamp. Projection Microscope 2 is specified for 220 V AC mains, whereas Projection Microscopes 1 is a dual-voltage version.
Related Projection Microscopes
- Projection Microscopes 1 — same graduated screen and objectives, with a dual-voltage lamp supply.
- Projection Microscopes — projection model with a glass screen and Huygenian eyepieces.
- Student Projection Microscope — student projection model with a straight tube and triple nosepiece.
Other models are in Microscope, which belongs to Microscope Lab Equipment.
Request a Quote
Add the model with Add To Cart, or send the quantity, the delivery location and any questions through our contact page.
