Student School Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-934
Jlab Export is a leading Student School Microscope Manufacturer,and suppliers in India
Student School Microscope (code EL-M-934) is a monocular compound microscope for school classes, with a straight fixed tube, an achromatic 10X objective and Huygenian 10X and 15X eyepieces. Light comes from a 25 mm plano-concave mirror on a gimbal mount, and stage clips hold the slide on a 75 x 85 mm fixed stage. JLab makes it in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Observation | Monocular, straight fixed tube |
| Stage | Fixed square, 75 x 85 mm, with stage clips |
| Illumination | Plano-concave mirror, 25 mm diameter, gimbal mount |
| Objective | Achromatic 10X |
| Eyepieces | Huygenian 10X and 15X |
| Total magnification | 100X and 150X |
| Quality check | Each microscope is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 5 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-M-934 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Choosing Between the 10X and 15X Eyepieces
The tube carries a single achromatic 10X objective, so there is no nosepiece to turn. Fitting the 10X eyepiece gives 100X total magnification for finding and centring a specimen; swapping in the 15X raises it to 150X for a closer look at the same field.
Lighting and Focusing a Slide
Clip the slide to the fixed stage with the specimen over the opening. Looking through the eyepiece, tilt the gimbal-mounted mirror until the field is evenly bright, using the flat face in strong light and the concave face when light is weak. Then focus slowly, watching from the side first so the objective does not touch the cover glass.
Related Student Microscopes
- Student Microscope — student model with the same 10X objective and 10X and 15X eyepieces.
- Student Compound Microscope — inclinable-tube model with a triple nosepiece and two objectives.
- Reflecting Mirror — glass reflecting mirror from the microscope parts range.
Every school and laboratory model is in Microscope, under Microscope Lab Equipment.
Request a Quote
Order through Add To Cart, or send the number of microscopes for the class and the school address through the contact page.
