Student Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-858
Jlab Export is a leading Student Microscope Manufacturer,and suppliers in India
Student Microscope (code EL-M-858) is a monocular compound microscope with a straight fixed tube, one achromatic 10X objective and Huygenian 10X and 15X eyepieces, lit by a plano-concave mirror. A fixed square stage with clips holds the slide, which keeps the instrument simple for pupils starting slide work. JLab manufactures the Student Microscope in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Observation | Monocular, straight fixed tube |
| Stage | Fixed square stage, 75 x 85 mm, with stage clips |
| Illumination | Plano-concave mirror, 25 mm diameter, on gimbal mount |
| Objective | Achromatic 10X |
| Eyepieces | Huygenian 10X and 15X |
| Total magnification | 100X and 150X |
| Quality check | Each microscope is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 5 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-M-858 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Magnification with One Objective
With the single 10X objective, the 10X eyepiece gives 100X total magnification and the 15X eyepiece gives 150X, so power is changed by swapping eyepieces rather than turning a nosepiece. Huygenian eyepieces are a simple two-lens design long used on teaching microscopes.
Setting Up the Mirror and Stage
The 25 mm plano-concave mirror sits on a gimbal mount and can be tilted to send light up through the slide: the flat face suits bright daylight or a lamp, and the concave face gathers weaker light. The slide is held on the 75 x 85 mm fixed stage by its clips and moved by hand.
Related Microscope Items
- Mechanical Stage — separate stage with rack and pinion movement and a vernier.
- Reflecting Mirror — glass reflecting mirror for microscopes lit by a mirror.
- Monocular Inclined Microscope — monocular model with an inclined rotating head and a quadruple nosepiece.
The compound and stereo models sit together in Microscope under Microscope Lab Equipment.
Request a Quote
Order through Add To Cart, or ask on the contact page for a quote covering your class quantity and delivery point.
