Digital Camera Microscope with Dual View Manufacturer,Supplier and Exporter in India
Product Code : EL-M-8048
Jlab Export is a leading Digital Camera Microscope with Dual View Manufacturer,and suppliers in India
Digital Camera Microscope with Dual View (code EL-M-8048) is an all-metal student microscope whose dual view head carries a digital camera, offered with a 1.3 MP or 3.0 MP sensor. Achromatic 4X, 10X and 40XR objectives work with a locked-on 10X eyepiece under built-in LED light, for 40X, 100X and 400X. JLab manufactures this camera model in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Viewing head | Dual view head with digital camera, 360° rotating, inclined at 45° |
| Eyepiece | Locked-on 10X wide-field with pointer |
| Objectives | Achromatic 4X, 10X and 40XR (retractable); colour-coded and parcentred; 3-position reverse nosepiece with click stops |
| Total magnification | 40X, 100X and 400X |
| Focusing | Coarse; rack and pinion with slip clutch; safety rack stop |
| Illumination | Built-in LED with on/off switch, 10,000-hour lifespan; 6-hole rotating disc diaphragm |
| Power | Three-wire grounded power cord |
| Camera options | 1.3 MP (1/3 in CMOS, 1280 × 1024) or 3.0 MP (1/2 in CMOS, 2048 × 1536) |
| Camera output | 640 × 480 at 30 fps; JPG/BMP images; manual/auto white balance; sensitivity 1.0 V/lux-sec |
| Stage and design | 3.5 in round gliding stage, 360°, with clips; 12 in high, 6.5 × 5.25 in base; all metal |
| Quality check | Each microscope is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 5 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-M-8048 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Choosing the 1.3 MP or 3.0 MP Camera
Both cameras use a CMOS sensor and save stills as JPG or BMP files, with manual or automatic white balance and a 30 fps rate at 640 × 480 pixels. The 1.3 MP version has a 1/3 in sensor with 3.6 µm pixels and a maximum of 1280 × 1024; the 3.0 MP version moves to a 1/2 in sensor with 3.18 µm pixels and 2048 × 1536, which suits images that will be enlarged or cropped.
The Microscope Below the Camera
Optically it matches the LED Corded/Cordless Dual View Microscope: a reverse nosepiece clicks between the colour-coded, parcentred objectives, a disc diaphragm with six openings adjusts the light for each power, and a slip clutch with safety rack stop guards the focusing gears and the specimen. This camera version runs from a three-wire grounded mains cord.
Related Dual View Microscopes
- Dual View with Digital Camera Coaxial Focusing Microscope — camera dual view model with coaxial coarse and fine focus
- LED Corded/Cordless Dual View Microscope — dual view LED design without the camera, corded or cordless
- Dual View Coaxial Focusing Beginner Microscope — dual view LED model with coaxial coarse and fine focusing
More camera, LED and student instruments appear in Microscope and Microscope Lab Equipment.
Request a Quote
Use Add To Cart or the contact page to order, stating the quantity and whether the 1.3 MP or the 3.0 MP camera is required.
