Monocular Laboratory Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-942
Jlab Export is a leading Monocular Laboratory Microscope Manufacturer,and suppliers in India
Monocular Laboratory Microscope (code EL-M-942) is a compound microscope with a monocular head inclined at 45 degrees and rotatable through 360 degrees, a quadruple nosepiece holding achromatic 4X, 10X and 40X SL objectives, and a 115 x 115 mm fixed square stage with two spring-mounted clips. Three Huygenian eyepieces come with it, chosen from five powers. JLab builds it in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Observation head | Monocular, inclined at 45 degrees, rotatable through 360 degrees |
| Nosepiece | Quadruple, positive click stops |
| Stage | Fixed square, 115 x 115 mm, two spring-mounted stage clips |
| Illumination | Plano-concave mirror, 50 mm, adjustable, gimbal mount; optional sub-stage illuminator |
| Objectives | Achromatic 4X, 10X and 40X SL |
| Eyepieces | Huygenian, any three of 5X, 6X, 10X, 15X and 16X |
| Total magnification | 20X to 640X |
| Quality check | Each microscope is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 5 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-M-942 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Three Eyepieces from Five Powers
The buyer picks three of the 5X, 6X, 10X, 15X and 16X Huygenian eyepieces. Choosing 5X, 10X and 15X, for example, gives 50X, 100X and 150X on the 10X objective, and 200X, 400X and 600X on the 40X SL. Across every combination the range runs from 20X, the 4X objective with a 5X eyepiece, to 640X, the 40X SL with a 16X.
Lighting the Fixed Stage
A 50 mm plano-concave mirror on a gimbal mount sends light up through the stage, and it can be exchanged for the optional sub-stage illuminator where a built-in source is preferred. The two spring-mounted clips keep the slide in place on the 115 x 115 mm stage while it is moved by hand between fields.
Related Microscopes
- Monocular Inclined Microscope — monocular model with the same inclined rotating head and 4X, 10X and 40X SL objectives.
- Binocular Laboratory Microscope — binocular model with a detachable graduated stage and sub-stage illuminator option.
- Mechanical Stage — rack and pinion slide stage with a vernier scale.
The rest of the monocular and binocular range is in Microscope, inside Microscope Lab Equipment.
Request a Quote
Say which three eyepiece powers should come with each microscope when you order through Add To Cart or the contact page, and include the quantity and delivery address.
