Steering System Actual Working Manufacturer,Supplier and Exporter in India
Product Code : EL-IEL-10109
Jlab Export is a leading Steering System Actual Working Manufacturer,and suppliers in India
Steering System Actual Working (code EL-IEL-10109) is a manual steering system of the worm and roller type, built from actual parts on a square iron pipe frame and kept in working form so the steering gear can be operated in class. It is dissectible for demonstration. This worm and roller steering unit is made by JLab in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Steering type | Manual, worm and roller |
| Construction | Actual steering parts |
| Frame | Square iron pipe |
| Form | Actual working |
| Dismantling | Dissectible for demonstration |
| Quality check | Each steering unit is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 14–18 working days |
| Product code | EL-IEL-10109 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Inside a Worm and Roller Steering Gear
The steering shaft ends in a worm, and a roller carried on the cross shaft engages its thread. Turning the steering wheel rotates the worm, the roller follows the thread, and the cross shaft swings through part of a turn, moving the drop arm that drives the linkage to the wheels. Because the roller rolls rather than slides on the worm, friction is lower than in a plain worm and sector gear, and several turns of the steering wheel give only a small swing of the drop arm, which keeps the driver’s effort down without power assistance.
Operating the working unit shows this gear reduction directly, and dismantling it lets students see how the worm and roller mesh.
Other Steering Units to Compare
- Rack and Pinion Type Steering System — the rack and pinion type, shown with actual parts in working form.
- Cut Section Model of Steering Gear Box — sectioned steering gear box showing the worm, steering arm and wheel movement.
- Manual Steering System — manual steering unit on a square iron pipe frame.
Steering gears, gear boxes and engine sections are collected under I.C. Engine Lab in the Engineering Lab Equipment section.
Request a Quote
Ask for a quotation with Add To Cart, or send the required quantity and your delivery address through the contact page.
