Vertical Electrophoresis System Manufacturer,Supplier and Exporter in India
Product Code : EL-ELA-5436
Jlab Export is a leading Vertical Electrophoresis System Manufacturer,and suppliers in India
Vertical Electrophoresis System (code EL-ELA-5436) is a mini-format vertical gel electrophoresis unit that runs one to four slab gels at a time, each 8.3 x 7.3 cm, using either precast or hand-cast gels. Units of this type are used mainly for polyacrylamide gel electrophoresis of proteins in biochemistry, biotechnology and molecular biology labs. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Format | Vertical slab gel electrophoresis |
| Number of gels | 1 to 4 |
| Gel types | Precast gels or hand-cast gels |
| Short plate (W x L) | 10.1 x 7.3 cm |
| Spacer plate (W x L) | 10.1 x 8.2 cm |
| Gel size (W x L) | 8.3 x 7.3 cm |
| Quality check | Each system is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-ELA-5436 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
What Is the Vertical Electrophoresis System Used For?
In vertical electrophoresis the gel stands upright between a short glass plate and a taller spacer plate, with buffer above and below it, so the current passes down through the gel and the samples separate by size as they move. This format suits polyacrylamide gels, so it is mainly used for SDS-PAGE and native PAGE of proteins, and also for separating small DNA fragments, in college and university biochemistry and biotechnology practicals and in research labs. Running up to four mini gels together lets a class or a research group compare several sets of samples in one run.
Frequently Asked Questions
How many gels can it run at once?
From one to four gels in a single run.
Can it be used with precast gels?
Yes. The system is listed for precast gels and for gels cast by hand between its glass plates.
What size are the gels and glass plates?
Each gel is 8.3 x 7.3 cm (width x length). The short plate measures 10.1 x 7.3 cm and the spacer plate 10.1 x 8.2 cm.
When should I choose a vertical rather than a horizontal system?
Choose vertical for polyacrylamide gels, mainly protein work such as SDS-PAGE; a horizontal (submarine) unit is the usual choice for agarose gels of DNA and RNA.
Who manufactures this electrophoresis system?
Jain Laboratory Instruments Pvt Ltd, trading as JLab, makes it at its works in Ambala, Haryana, India.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, a life-science and educational laboratory equipment manufacturer in India, incorporated in 2017 and located on Hargolal Road, Ambala, Haryana. The vertical system is produced at JLab’s own works instead of being bought from a trader, so universities, colleges, dealers and importers order it factory-direct; every unit is inspected visually before dispatch, and repeat orders and spare parts are handled by the manufacturer. The company is registered under CIN U29309HR2017PTC069123 and holds MSME Udyam registration UDYAM-HR-01-0003849 (manufacturing enterprise). JLab exports worldwide and ships to buyers in every region — for example the Netherlands in Western Europe, Sri Lanka in South Asia, Togo in West Africa, Romania in Eastern Europe and Thailand in Southeast Asia. Tender details are on the JLab lab tenders page.
Other Gel Electrophoresis Equipment
- Electrophoresis Horizontal — a mini horizontal (submarine) unit for DNA and RNA gels.
- Gel Electrophoresis System — apparatus listed for separating DNA, RNA or proteins by molecular size.
- Electrophoresis Power Supply, Digital, Variable — a digital supply with constant-current and constant-voltage modes and a timer; a separate item that can be quoted on the same enquiry.
Browse the Educational Laboratory Apparatus section or the full Laboratory Apparatus range.
Request a Quote
Ask for a quotation with the Add To Cart button on this page or through the contact page; include the number of systems, any power supply or other items you want on the same quote, and the destination country and city.
