White Light Source Ray Box Manufacturer,Supplier and Exporter in India
Product Code : EL-CL-13462
Jlab Export is a leading White Light Source Ray Box Manufacturer,and suppliers in India
White Light Source Ray Box (code EL-CL-13462) is a ray box that sends five separate, parallel beams of white light, supplied as a demonstration set with a demonstration board and five types of large lenses: double convex, double concave, plano-concave, plano-convex and concave-convex. The large lenses let a whole class follow the rays on the board while studying the laws of refraction. JLab builds the ray box and lens set in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Model | JL/IPL-701 |
| Light source | White light |
| Beams | Five separate parallel beams |
| Lens set | Demonstration set of 5 types of large lenses, with demonstration board |
| Lens types | Double convex, double concave, plano-concave, plano-convex, concave-convex |
| Quality check | Each ray box set is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 4–6 working days |
| Product code | EL-CL-13462 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Watching the Rays Meet at the Focal Point
Put the double convex lens in the path of the five beams and each ray is refracted inwards; the beams cross at one shared point, the focal point, and spread apart again beyond it. Measuring from the centre of the lens to that crossing point gives the focal length directly. The plano-convex lens also brings the beams together.
Swap in the double concave or plano-concave lens and the beams spread outwards instead, as though they started from a point on the ray-box side of the lens. Setting the shapes side by side shows that lenses thicker in the middle converge light and lenses thinner in the middle diverge it.
