Digital HB Reader LCD Alpha Numeric

Digital HB Reader LCD Alpha Numeric

Product Code : JL-PALE-9840

Digital HB Reader LCD Alpha Numeric
Programmable with Memory
A very light weight, accurate & reliable Haemoglobin reader based on “Cyanmethemoglobin method”.
It gives direct reading of unknown solution in concentration (gm/dl) without any calculations.
A microcontroller has been incorporated in the system for accuracy & reproducibility of the findings.
It operates in “Measurement & Calibration” mode.
The 15 gm/dl. Concentration of standard solution has been fed as a default value, however you can change this value by going into “Calibration” mode.
Technical Specifications:-

Wavelength Range:-

-546 ± 5 mm

Minimum Volume:-

-1 ml

Display:-

16X1 LCD Alpha numeric

Key Pad:-

2X2 Soft Touch

Light Source:-

Green Colour LED

Detector:-

Silicon photo diode

Memory:-

40 Tests Storage Facility

Auto Zero:-

Available

Input supply:-

-Mains : 220 ± 10%, 50Hz, 1 Æ

Battery:-

12 VDC

Dimensions:-

215 X 150 X 100 mm

Test Tubes:-

Square 10 X 10 mm (Plastic)

Weight:-

1 1/2 kg. Net
