Experimentation with Logic Gates Manufacturer,Supplier and Exporter in India
Product Code : EL-BE-10497
Jlab Export is a leading Experimentation with Logic Gates Manufacturer,and suppliers in India
Experimentation with Logic Gates (code EL-BE-10497) is a compact logic gate trainer for digital laboratories on which students connect every experiment themselves with patch cords, so they learn the inputs and outputs of each gate as they wire it. Its input and output sections are arranged so that several experiments can be performed at the same time. JLab builds the trainer in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Gates covered | AND, OR, NOT, NAND, NOR, XOR and XNOR |
| Connections | Links made by the student with patch cords |
| Layout | Input and output sections arranged so that multiple experiments can be performed simultaneously; straightforward representation of all the logic gates |
| Power | +5V SMPS adaptor provided with the trainer |
| Design | Compact |
| Learning support | Online product tutorial |
| Quality check | Each trainer is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-BE-10497 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How Does It Compare with Other JLab Logic Gate Trainers?
| Model | Gates and circuits | Power | How circuits are connected |
|---|---|---|---|
| This trainer (EL-BE-10497) | AND, OR, NOT, NAND, NOR, XOR and XNOR truth tables | +5V SMPS adaptor | Patch-cord links |
| Training Board for Gates | OR, AND and NAND gates; OR, NOR, NOT, AND and EX-OR functions built from NAND gates | Built-in +5 V DC supply | Patch cords |
| Logic Gates Circuit Trainer | AND, OR, NAND, NOR and NOT gates plus flip-flop units; Boolean algebra and adders | Regulated 5 V supply | Solderless breadboard |
Choose by the gate set and wiring method shown in the table: Training Board for Gates concentrates on building functions from universal NAND gates, and the Logic Gates Circuit Trainer is breadboard-based, with flip-flop units as well as gates.
What Is Experimentation with Logic Gates Used For?
It is used to understand the basic concepts and functioning of logic gates and their truth tables. Each experiment studies one gate, AND, OR, NOT, NAND, NOR, XOR or XNOR, and verifies its truth table by applying every combination of inputs and noting the output. Because the students make the links themselves, the trainer presents all seven gates in a very easy way while still showing how each one is wired.
What to Specify When Ordering
- Model — this trainer or one of the logic gate trainers compared above.
- Quantity — the number of trainers.
- Next-step trainers — the flip-flop and digital circuit trainers below are separate items for the same enquiry.
Frequently Asked Questions
What is the difference between the XOR and XNOR gates?
An XOR (exclusive-OR) gate gives a high output only when its inputs differ, which makes it the core of binary adders and parity checkers. An XNOR gate is its inverse: the output is high when the inputs are the same, so it acts as a simple equality detector.
How do NAND and NOR gates relate to AND and OR?
A NAND gate is an AND gate followed by an inverter, and a NOR gate is an OR gate followed by an inverter, so their outputs are the opposite of AND and OR for every input combination.
What is a truth table?
It lists the output of a gate for every possible combination of inputs. A two-input gate has four rows, and checking each row on the trainer confirms the gate behaves as its Boolean expression says.
How is the trainer powered?
A +5V SMPS (switch-mode power supply) adaptor is provided with the trainer; +5 V is the standard supply for TTL logic circuits.
What information should an export enquiry contain?
The quantity, the destination country and port or city, the delivery terms you prefer (for example FOB or CIF), any packing or labelling requests, and the tender reference if it is a tender purchase.
Who manufactures Experimentation with Logic Gates?
JLab, trading name of Jain Laboratory Instruments Pvt Ltd, manufactures the trainer in Ambala, Haryana, and quotes for it directly.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, a manufacturer of digital and analog electronics trainers and other educational laboratory equipment in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. The logic gates trainer is made at JLab's own works rather than sourced from a trader, so schools, colleges, dealers and importers buy direct from the factory, every unit is visually inspected before dispatch, and the manufacturer itself takes care of repeat orders. JLab exports worldwide and ships to buyers in every region — the USA in North America, Guinea in West Africa, Iraq in the Middle East, Libya in North Africa and Estonia in Northern Europe, for example. Tender information is on the JLab lab tenders page.
Related Digital Logic Trainers
- Training Board for Gates — compared above; functions built from universal NAND gates.
- Logic Gates Circuit Trainer — compared above; breadboard trainer with gate and flip-flop units.
- Understanding Digital Logic Circuits — gate and RS, D and JK flip-flop truth tables on on-board circuits marked with their logic symbols.
- Digital Work Station — more than 51 digital electronics experiments, chosen from a graphical LCD menu.
- Digital Circuits Development Platform (8-bit data switches and LED display) — breadboard platform for counters, shift registers and code converters.
The Basic Electronics range and the wider Electronics Lab Equipments section have more trainers.
Request a Quote
Request a quotation through the Add To Cart enquiry button on this page or the contact page, stating the number of trainers and the delivery destination.
