Fixed Tube Sheet Multi Pass Manufacturer,Supplier and Exporter in India
Product Code : EL-AM-5937
Jlab Export is a leading Fixed Tube Sheet Multi Pass Manufacturer,and suppliers in India
Fixed Tube Sheet Multi Pass (code EL-AM-5937) is a scale model of a typical multi-pass fixed tube sheet heat exchanger of the kind found in industry. It is built to support training in the operation and maintenance of industrial heat exchangers. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Model type | Scale model of a multi-pass fixed tube sheet heat exchanger |
| Represents | A typical heat exchanger found in industry |
| Shell | Clear acrylic |
| Construction | Can be completely disassembled |
| Training use | Operation and maintenance of industrial heat exchangers |
| Quality check | Each model is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-AM-5937 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
What Is the Fixed Tube Sheet Multi Pass Model Used For?
In a shell-and-tube heat exchanger one fluid runs through the tubes while the other flows around them inside the shell. In a multi-pass unit the tube-side fluid travels the length of the shell more than once before it leaves, which gives it a longer path for heat transfer than a single pass. The clear acrylic shell lets trainees see how the tubes are laid out inside, and because the model comes completely apart, the parts that operators and maintenance staff need to recognise can be handled one by one.
What to Specify When Ordering
- The number of models.
- Which exchanger design — this multi-pass fixed tube sheet model or the single-pass, floating-head and plate designs listed below.
- Any reboiler or other process models to be quoted on the same enquiry.
Frequently Asked Questions
What does “fixed tube sheet” mean?
The tube sheets, the plates that hold the ends of the tubes, are fixed to the shell at both ends. In a real exchanger of this type the tube bundle therefore stays in the shell, which keeps the construction simple but means the outside of the tubes cannot be reached for mechanical cleaning.
How does it differ from the single-pass version?
In a single-pass exchanger the tube-side fluid crosses the shell once; in a multi-pass exchanger it makes more than one pass. The Fixed Tube Sheet Single Pass is linked below.
What should an export quotation request include?
The quantity, the destination country and port or city, preferred delivery terms such as FOB or CIF, any packing or labelling needs and the tender reference, if there is one.
Who manufactures the Fixed Tube Sheet Multi Pass model?
Jain Laboratory Instruments Pvt Ltd (JLab) makes it at its works in Ambala, Haryana, India.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, a manufacturer of laboratory, teaching and training equipment in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. The model is made in JLab’s own works rather than sourced from a trader, so training institutes, colleges, dealers and importers buy it from the manufacturer and come back to the same works for repeat orders. JLab exports worldwide and ships to buyers in every region — for example Liberia in West Africa, South Korea in East Asia, Hungary in Eastern Europe, Uruguay in South America and Trinidad and Tobago in Central America and the Caribbean. Tender buyers can find details on the JLab lab tenders page.
Other Heat Exchanger Training Items
- Fixed Tube Sheet Single Pass — the single-pass version of the fixed tube sheet design.
- Multi Pass Floating Head — the multi-pass design with a floating head.
- Multi Port Plate Exchanger — a multi-port plate-type exchanger.
- Kettle Type Reboiler — steam flows through the tube bundle while the column bottoms flow through the shell side.
- Shell and Tube Heat Exchanger — a laboratory apparatus with an SS shell and copper tubes for studying LMTD, the overall heat transfer coefficient and the heat transfer rate at various flow rates.
This model sits in the Anatomical Models section of the educational equipment range.
Request a Quote
For a quotation, use the Add To Cart enquiry button or write through the contact page, giving the quantity, the exchanger designs you are interested in and the delivery destination.
