NAND Gate Trainer Manufacturer,Supplier and Exporter in India
Product Code : EL-ELA-5382
Jlab Export is a leading NAND Gate Trainer Manufacturer,and suppliers in India
NAND Gate Trainer (code EL-ELA-5382) is an electronic circuit demonstration model of the NAND logic gate — a gate that performs the AND function and then inverts the output. Teachers use it to show a class how a NAND gate behaves, with all its components fitted in place on the model. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Gate demonstrated | NAND (NOT-AND) |
| Function | AND function with an inverted output |
| Type | Electronic circuit demonstration model |
| Construction | Components fitted in place on the model |
| Quality check | Each trainer is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-ELA-5382 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
What Is the NAND Gate Trainer Used For?
The trainer turns the NAND truth table into something a class can watch. A NAND gate gives a LOW output only when every input is HIGH, and a HIGH output for any other combination — exactly the opposite of an AND gate. Stepping through the input combinations lets students write the truth table themselves. The NAND gate is also called a universal gate, because NOT, AND and OR functions can all be built from NAND gates alone, which makes the model a good opener for logic-gate lessons in school, ITI, polytechnic and college electronics labs.
Frequently Asked Questions
What does a NAND gate do?
It performs the AND function and inverts the result. The output is LOW only when all inputs are HIGH; every other input combination gives a HIGH output.
How is it different from the AND Gate Trainer?
The two gates give opposite outputs for the same inputs: an AND gate goes HIGH only when all inputs are HIGH, while the NAND gate goes LOW in that case. JLab lists the AND gate trainer separately, linked below.
How many inputs and what power supply does it have?
The listing does not state them. Ask JLab when you enquire, and the quotation will confirm the inputs, indicators and power arrangement of the unit supplied.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, an Indian manufacturer of school science and electronics teaching equipment, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. The NAND gate trainer comes from JLab’s own works rather than from a trader, so schools, colleges, dealers and importers order it factory-direct and repeat orders are handled by the manufacturer. JLab exports worldwide and ships to buyers in every region — for example Botswana in Southern Africa, Georgia in Eastern Europe, Iceland in Northern Europe, Tonga in Oceania and Paraguay in South America. For tender purchases, see the JLab lab tenders page.
Other Logic Gate Trainers
- And Gate Trainer — the AND gate, whose output the NAND gate inverts.
- Verification of truth tables of Logic gates using NAND Gate — uses NAND gates alone to build and verify other gate functions.
- Logic Gate Trainer — AND, OR, NOR and EX-OR gates and flip-flops on one digital electronics trainer kit.
- Nor Gate Trainer, OR Gate Trainer and EX-OR Gate Trainer — single-gate models to complete a set.
Browse more in Educational Laboratory Apparatus or the full Laboratory Apparatus range.
Request a Quote
Quotes come direct from the manufacturer. Use the Add To Cart enquiry button on this page, or send the quantity (minimum 10 units), any other gate trainers you want in the same shipment and your delivery location through the contact page.
