Pathological and Medical Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-864
Jlab Export is a leading Pathological and Medical Microscope Manufacturer,and suppliers in India
Pathological and Medical Microscope (code EL-M-864) is a compound microscope with a stand assembled from aluminium die-cast parts, a quadruple nosepiece carrying achromatic 10X, 40X SL and 100X SL oil immersion objectives, and a detachable graduated mechanical stage. Light comes from a 50 mm plano-concave mirror, which can be exchanged for an optional sub-stage illuminator. JLab builds this microscope in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Stand | Assembled from aluminium die-cast parts |
| Nosepiece | Quadruple, centred, with positive click stops |
| Stage | Detachable horizontal graduated mechanical stage, 120 x 120 mm; slide movement up to 45 x 75 mm |
| Illumination | Plano-concave adjustable mirror, 50 mm, on gimbal mount; interchangeable with an optional sub-stage illuminator |
| Objectives | Achromatic 10X, 40X SL and 100X SL oil immersion |
| Eyepieces | Huygenian 10X and 15X, or WF 10X |
| Total magnification | 100X, 400X and 1000X with a 10X eyepiece |
| Quality check | Each microscope is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 5 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-M-864 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Objectives, Eyepieces and Total Magnification
Multiply each objective by the eyepiece in use: with a 10X eyepiece, Huygenian or WF, the three objectives give 100X, 400X and 1000X; the 15X Huygenian raises them to 150X, 600X and 1500X. The 40X and 100X objectives are spring-loaded (SL), so the front lens can give way if it touches the slide, and the 100X is used with a drop of immersion oil between lens and cover glass.
Moving the Slide on the Mechanical Stage
The graduated stage measures 120 x 120 mm and carries a slide through a range of up to 45 x 75 mm, so a field can be found again from its scale readings. The nosepiece clicks positively into place at each objective as power is changed.
Related Microscopes and Parts
- Student Medical Microscope — student model with the same die-cast stand and mechanical stage.
- Achromatic Objectives — achromatic objectives from 2x up to 100x oil immersion.
- Binocular Microscope — binocular model with halogen lighting and a 100X oil immersion objective.
Compare it with the other compound microscopes in Microscope, part of Microscope Lab Equipment.
Request a Quote
Send an order with Add To Cart, or use the contact page to state your eyepiece choice (Huygenian 10X and 15X, or WF 10X), the quantity and the delivery address.
