Threading Tool Holder Manufacturer,Supplier and Exporter in India

Threading Tool Holder

Product Code : EL-MMTM-8948
Jlab Export is a leading Threading Tool Holder Manufacturer,and suppliers in India

External threads are cut on the lathe with this holder, which carries a carbide insert with the thread form on its tip. The insert is held by a clamp lock or a pin lock, so it can be turned to a fresh edge or replaced quickly. The shank is offset, with neutral rake and a 10° end edge angle.

Specifications

InsertCarbide, thread form
Insert lockingClamp lock or pin lock, positive locking action
Insert adjustmentFully adjustable
ShankOffset
End cutting edge angle10°
RakeNeutral
UseExternal threading
Length3-15/16 in including the insert
Minimum order quantity10 units
Dispatch timeUsually 4–6 working days
ManufacturerJLab (Jain Laboratory Instruments Pvt Ltd), Ambala, India

Thread Cutting Practicals

Screw cutting is a core job in the turner and machinist trades. On the Center Lathe Machine, students set the change gears, square the insert to the work with a Center Gauge and engage the half nut for each pass. After the last pass the pitch is checked with a Thread Gauge. The fit is then tried in a nut tapped with the Tap & Die Set, Metric Small.

Teachers use the job to explain thread depth, infeed with the compound slide, and why every pass must start in step with the one before. A common student mistake is an insert set above or below centre height, which distorts the thread form.

Frequently Asked Questions

Can this holder cut internal threads?
No. It is made for external threading only. The offset shank lets the insert cut close to a shoulder or the chuck. Internal threads need a boring-type threading bar that fits inside the hole.

What thread angle does it cut?
The thread form comes from the insert, not the holder. Fit an insert ground to the form you need, and check it against a centre gauge before cutting. Because the rake is neutral, the profile on the insert is the profile cut into the work.

How is the insert set square to the work?
Hold a centre gauge against the turned diameter and bring the insert into its V-notch. Move the holder in the tool post until no light shows on either flank, then lock it. Set the insert tip at centre height before tightening.

How is the insert turned or changed?
Release the clamp lock or pin lock, turn the insert to a fresh edge or fit a new one, and lock it again. The positive locking holds the insert firmly in its seat. Check the setting with the centre gauge after each change.

Other Tool Holders and Bars

For a quote, use Add To Cart or send us a message through the contact page.
