Wiring Accessories Manufacturer,Supplier and Exporter in India
Product Code : EL-MWLE-13061
Jlab Export is a leading Wiring Accessories Manufacturer,and suppliers in India
Long duct runs on an outside wall are built from straight lengths, and a connection piece joins one length to the next. This one is the connection for 80 x 60 mm pipe and cable duct on a split air conditioner installation. It covers the joint, so the line set stays enclosed across the seam.
Specifications
| Part | Connection for pipe and cable duct |
| Size | 80 x 60 mm |
| Application | Split air conditioner installation |
| Minimum order quantity | 50 units |
| Dispatch time | Usually 3–5 working days |
| Manufacturer | JLab (Jain Laboratory Instruments Pvt Ltd), Ambala, India |
Workshop Practice: Running the Duct
Once the wall hole and line set are ready, trainees measure the outdoor run. They cut the Base And Cover duct to length using a hacksaw and the 12 in Hack Saw Blades. Each cut end is filed square, so two lengths butt together without a gap. The connection is then fitted over the joint to hold the two lengths in line.
Teachers can give each group a run of a set length, so students plan where every joint falls before they fix the base to the wall. Inside the duct, the lines wrapped in Copper Pipe Insulation should lie flat and must not be pinched at a joint when the cover is closed.
Frequently Asked Questions
What does the connection do in a duct run?
It joins two straight lengths of duct end to end. The joint stays covered, so the pipes, drain hose and cable are not left exposed at the seam.
Is a duct better than wrapping the pipes in tape?
On a long straight run along a wall, a duct protects the insulation from sun and knocks and keeps the wall tidy. Tape or a brushed coating suits short runs and lines with many bends, where a rigid duct cannot follow the pipe. Many installations use both.
Does it fit duct of another size?
No. It is made for 80 x 60 mm duct, the size of the Base And Cover duct in this range. A duct of another width or depth would leave a gap at the joint.
Why put the line set in a duct at all?
A duct shields the pipe insulation from sunlight and knocks, keeps the drain hose and cable together and leaves the outside wall tidy. Bare foam insulation left in strong sun breaks down over time.
More Duct and Line-Set Items
- Wall Cover (80 mm, for the wall hole)
- Cover Ending (end piece for the duct)
- Copper Pipe (10 mm and 12 mm rolls)
For a quote, use Add To Cart or send us a message through the contact page.
